FUEL INJECTION SYSTEM
8-20
TIP
Make sure that the machine is completely cold before checking the coolant temperature sensor.
Fault code 21
Symptom Coolant temperature sensor: open or short circuit detected.
Fail-safe system Able to start engine
Able to drive vehicle
Diagnostic code No. 06
Diagnostic tool display Displays the coolant temperature.
Procedure Compare the actually measured coolant temperature with the
Yamaha diagnostic tool display value.
Or-
der
Probable cause of malfunc-
tion and check
Maintenance job Reinstatement method
1 Connection of coolant tem-
perature sensor coupler.
Check the locking condition
of the coupler.
Disconnect the coupler, and
check the pins (for bent or
broken terminals and locking
condition of the pins).
Improperly connected 
Connect the coupler secure-
ly, or repair/replace the wire
harness.
Turn “ON” the switch on the
FI diagnostic tool sub-lead.
Fault code No. is not dis-
played  Repair is finished.
Fault code No. is displayed 
Go to next order.
2 Connection of wire harness
ECU coupler.
Check the locking condition
of the coupler.
Disconnect the coupler, and
check the pins (for bent or
broken terminals and locking
condition of the pins).
Improperly connected 
Connect the coupler secure-
ly, or repair/replace the wire
harness.
Turn “ON” the switch on the
FI diagnostic tool sub-lead.
Fault code No. is not dis-
played  Repair is finished.
Fault code No. is displayed 
Go to next order.
3 Wire harness continuity. Open or short circuit  Re-
place the wire harness.
Between coolant temperature
sensor coupler and ECU cou-
pler.
green/white–green/white
black/blue–black/blue
Turn “ON” the switch on the
FI diagnostic tool sub-lead.
Fault code No. is not dis-
played  Repair is finished.
Fault code No. is displayed 
Go to next order.
4 Mounted condition of coolant
temperature sensor.
Check for looseness or
pinching.
Check the mounted condition
for correctness.
Improperly mounted sensor
 Remount or replace the
sensor.
Turn “ON” the switch on the
FI diagnostic tool sub-lead.
Fault code No. is not dis-
played  Repair is finished.
Fault code No. is displayed 
Go to next order.
5 Defective coolant tempera-
ture sensor.
Execute the diagnostic mode.
(Code No. 06)
When the machine is cold,
displayed temperature is
close to the ambient temper-
ature.
Improper display  Replace
the coolant temperature sen-
sor.
Turn “ON” the switch on the
FI diagnostic tool sub-lead.
Fault code No. is not dis-
played  Repair is finished.
Fault code No. is displayed 
Go to next order.
6 Faulty ECU Replace the ECU.
