FUEL INJECTION SYSTEM
8-23
Fault code 33
Symptom
Ignition coil: open or short circuit detected in the primary lead
of the ignition coil.
Fail-safe system Unable to start engine
Unable to drive vehicle
Diagnostic code No. 30
Actuation Actuates the ignition coil five times at one-second intervals.
“WARNING” on the Yamaha diagnostic tool blinks five times when-
ever the ignition coil is actuated.
Procedure Check that a spark is generated five times.
• Connect an ignition checker.
Or-
der
Probable cause of malfunc-
tion and check
Maintenance job Reinstatement method
1 Connection of ignition coil
coupler.
Check the locking condition
of the coupler.
Disconnect the coupler, and
check the pins (for bent or
broken terminals and locking
condition of the pins).
Improperly connected
Connect the coupler secure-
ly, or repair/replace the wire
harness.
After starting the engine, idle
this and wait about 5 sec-
onds.
Fault code No. is not dis-
played Repair is finished.
Fault code No. is displayed
Go to next order.
2 Connection of wire harness
ECU coupler.
Check the locking condition
of the coupler.
Disconnect the coupler, and
check the pins (for bent or
broken terminals and locking
condition of the pins).
Improperly connected
Connect the coupler secure-
ly, or repair/replace the wire
harness.
After starting the engine, idle
this and wait about 5 sec-
onds.
Fault code No. is not dis-
played Repair is finished.
Fault code No. is displayed
Go to next order.
3 Wire harness continuity. Open or short circuit Re-
place the wire harness.
Between ignition coil coupler
and ECU coupler.
orange–orange
After starting the engine, idle
this and wait about 5 sec-
onds.
Fault code No. is not dis-
played Repair is finished.
Fault code No. is displayed
Go to next order.
4 Mounted condition of ignition
coil.
Check for looseness or
pinching.
Check the mounted condition
for correctness.
Improperly mounted ignition
coil Remount or replace
the ignition coil.
After starting the engine, idle
this and wait about 5 sec-
onds.
Fault code No. is not dis-
played Repair is finished.
Fault code No. is displayed
Go to next order.
5 Defective ignition coil (test
the primary coils for continu-
ity).
Check the primary resistance
of the ignition coil.
“CHECKING THE IGNITION
COIL” on page 8-41.
After starting the engine, idle
this and wait about 5 sec-
onds.
Fault code No. is not dis-
played Repair is finished.
Fault code No. is displayed
Go to next order.
To Next Page
