FUEL INJECTION SYSTEM
8-27
Fault code 46
Symptom
Vehicle system power supply: normal voltage is not supplied
to the ECU.
Fail-safe system Able/Unable to start engine
Able/Unable to drive vehicle
Diagnostic code No. —
Diagnostic tool display —
Procedure —
Or-
der
Probable cause of malfunc-
tion and check
Maintenance job Reinstatement method
1 Connection of wire harness
ECU coupler.
Check the locking condition
of the coupler.
Disconnect the coupler, and
check the pins (for bent or
broken terminals and locking
condition of the pins).
Improperly connected
Connect the coupler secure-
ly, or repair/replace the wire
harness.
After starting the engine, idle
this, turn “OFF” the switch on
the FI diagnostic tool sub-
lead, and wait about 5 sec-
onds or more.
Fault code No. is not dis-
played Repair is finished.
Fault code No. is displayed
Go to next order.
2 Wire harness continuity. Open or short circuit Re-
place the wire harness.
Between rectifier/regulator
and ECU coupler
red–red
Between condenser and
ECU coupler
red–red
After starting the engine, idle
this, turn “OFF” the switch on
the FI diagnostic tool sub-
lead, and wait about 5 sec-
onds or more.
Fault code No. is not dis-
played Repair is finished.
Fault code No. is displayed
Go to next order.
3 Faulty AC magneto Check the AC magneto.
“CHECKING THE AC MAG-
NETO” on page 5-59.
After starting the engine, idle
this, turn “OFF” the switch on
the FI diagnostic tool sub-
lead, and wait about 5 sec-
onds or more.
Fault code No. is not dis-
played Repair is finished.
Fault code No. is displayed
Go to next order.
4 Faulty ECU Replace the ECU.
To Next Page
