Yamatake MGG14C - Electrical Wiring (6); Figure 2-8 Outer Dimensions of Excitation Cables; Figure 2-9 Excitation Cable Construction

2 - 10
Excitation Cables
(Model: MGA 12W)
Figure 2-8 Outer Dimensions of Excitation Cables
For M4 screw
For M4 screw
For M4 screw
For M4 screw
For M4 screw
For M4 screw
Insulating tube
Detector side
Converter side
Terminal treatment on detector side
Black
Detector side
White
(Model A)
Black
White
Detector side
(Model A)
(Model B)
Black
White
Detector side
(Model B)
Black
White
Detector side
Figure 2-9 Excitation Cable Construction
Sheath
Insulator
Conductive wire
Cloth tape
Electrical Wiring (2) Continued
