Engineering Mode
Introduction
The Engineering Mode contains the following settings and adjustments.
ID SET
FUNC SET
DUMMY
HYSTERESIS
I. OUT RANGE
SPAN
GRAVITY
Selects the coefficient of
compensation
COEFFICIENT
Indicated conditionsDescriptionScreen display
Sets the ID
Sets the functions
Sets detector dataEX, TYPE, DIA
Sets the number of dummy
detectors
Selection of an NNK detec-
tor in the detector data set-
ting.
Sets the range
Sets the hysteresis
Selection of normal direc-
tion automatic double
range or normal/reverse di-
rection automatic double
range in function setting.
Selects the electromagnetic
output method
Selection of normal direc-
tion automatic or external
double range or normal/re-
verse direction automatic or
external double range in
function setting.
Selects the specific gravity
Selection of a weight unit
(t, kg, g, lb) in range setting.
PLS WID
PLS SCL
DROP OUT
Sets the pulse scale
Selection of pulse output
(option).
Selects the pulse width
Selection of pulse output
(option).
Sets the drop out
Selection of pulse output
(option).
(Continued on next page)
