Yamatake MGG14C - Relations for Setting Function FXXXX

4 - 27
Relations for Setting Function FXXXX
Introduction
The range, built-in counter, contact input, and contact output functions can be
set using the combinations shown in the table below. For example, when
“Single range” and “Addition with preset” are selected, there are three contact
input choices (X, 1, and 2) and three contact output choices.
1-contact input and 1-contact output (DI/DO)
Range function Built-in counter function Contact input function Contact output function
0: Single range X: Not activated X: Not activated X: Not activated
1: Alarm output
4:
Self-check result output
5: Empty detection function
6: High/low limit alarm
1: External 0% lock X: Not activated
1: Alarm output
4:
Self-check result output
5: Empty detection function
6: High/low limit alarm
2: External auto zero adjustment X: None
1: Alarm output
4:
Self-check result output
5: Empty detection function
6: High/low limit alarm
A: Addition X: Not activated X: Not activated
1: Alarm output
4:
Self-check result output
5: Empty detection function
6: High/low limit alarm
1: External 0% lock X: Not activated
1: Alarm output
4:
Self-check result output
5: Empty detection function
6: High/low limit alarm
2: External auto zero adjustment X: Not activated
1: Alarm output
4:
Self-check result output
5: Empty detection function
6: High/low limit alarm
4: Counter reset X: None
1: Alarm output
4:
Self-check result output
5: Empty detection function
6: High/low limit alarm
B: Addition with preset X: Not activated 3: Preset output
1: External 0% lock 3: Preset output
2: External auto zero adjustment 3: Preset output
(Continued on next page)
