Range Functions Continued
Normal direction,
external switching
double range
The range is switched via an external switching command contact input.
Also, the wide/narrow range distinction contact output (status signal) can be
sent out using the same timing.
Analog output
1 When AUTO is selected for an analog output
Range No.1 4 - 20 mA DC
Range No.2 4 - 20 mA DC
2 When WIDE is selected for an analog output
4 - 20 mA DC is output according to either range No.1 or range No.2
whichever has the wider span.
When there is a pulse output
The pulse scale is the same for both ranges No.1 and No.2.
Contact input
Range switching command contact input
Range No.1: Open
Range No.2: Closed
Contact output (select functions as required.)
Range switching distinction status signal
The contact output status at shipment is as follows.
Range No.1: Open
Range No.2: Closed
Reverse setting is also possible.
(Continued on next page)
