4 - 40
"Contact Output Function" Continued
A: High/low limit alarm and range switching output (2-contact output)
The high/low limit alarm can be set to ST.OUT1 and the range switch-
ing output to ST.OUT2.
B: Range switching output and counter preset status output (2-contact out-
put)
The range switching output can be set to ST.OUT1 and the preset status
output to ST.OUT2.
C: Range switching output and (self-check result output or empty detection)
(2-contact output)
The range switching output can be set to ST.OUT1 and the output when
either a self-check result or empty detection abnormality occurs to
ST.OUT2.
D: Alarm contact output and counter preset status output (2-contact output)
The alarm contact output can be set to ST.OUT1 and the counter preset
status output to ST.OUT2.
E: 2-stage flow rate alarm output
The high/low limit alarm can be set to ST.OUT1 and the 2-stage high
limit alarm or 2-stage low limit alarm to ST.OUT2.
To Next Page
