Receiving
1
1.2 Model Number and Nameplate Check
YASKAWA SIEPC71061753C GA500 Technical Manual 23
Table 1.3 Three-Phase AC 200 V Class
Model
Heavy Duty Rating (HD)
[C6-01 = 0]
(Default)
Normal Duty Rating (ND)
[C6-01 = 1]
Maximum Applicable Motor
Output
kW (HP)
Rated Output Current
A
Maximum Applicable Motor
Output
kW (HP)
Rated Output Current
A
2001 0.1 (1/6) 0.8 0.18 (1/6) 1.2
2002 0.25 (1/4) 1.6 0.37 (1/4) 1.9
2004 0.55 (1/2) 3.0 0.75 (3/4) 3.5
2006 1.1 (1) 5.0 1.1 (1.5) 6.0
2008 1.1 (1.5) 6.9 1.5 (2) 8.0
2010 1.5 (2) 8.0 2.2 (3) 9.6
2012 2.2 (3) 11.0 3.0 (4) 12.2
2018 3.0 (4) 14.0 4.0 (5) 17.5
2021 4.0 (5) 17.6 5.5 (7.5) 21.0
2030 5.5 (7.5) 25.0 7.5 (10) 30.0
2042 7.5 (10) 33.0 11.0 (15) 42.0
2056 11.0 (15) 47.0 15.0 (20) 56.0
2070 15.0 (20) 60.0 18.5 (25) 70.0
2082 18.5 (25) 75.0 22.0 (30) 82.0
Table 1.4 Three-Phase AC 400 V Class
Model
Heavy Duty Rating (HD)
[C6-01 = 0]
(Default)
Normal Duty Rating (ND)
[C6-01 = 1]
Maximum Applicable Motor
Output
kW (HP)
Rated Output Current
A
Maximum Applicable Motor
Output
kW (HP)
Rated Output Current
A
4001 0.37 (1/2) 1.2 0.37 (1/2) 1.2
4002 0.55 (3/4) 1.8 0.75 (1) 2.1
4004 1.1 (2) 3.4 1.5 (2) 4.1
4005 1.5 (3) 4.8 2.2 (3) 5.4
4007 2.2 (3) 5.6 3.0 (4) 7.1
4009 3.0 (4) 7.3 4.0 (5) 8.9
4012 4.0 (5) 9.2 5.5 (7.5) 11.9
4018 5.5 (10) 14.8 7.5 (10) 17.5
4023 7.5 (10) 18.0 11.0 (15) 23.4
4031 11.0 (15) 24.0 15.0 (20) 31.0
4038 15.0 (20) 31.0 18.5 (25) 38.0
4044 18.5 (25) 39.0 22.0 (30) 44.0
4060 22.0 (30) 45.0 30.0 (40) 60.0
