1.2 Model Number and Nameplate Check
22 YASKAWA SIEPC71061753C GA500 Technical Manual
Table 1.1 Model Number Details
No. Description
1 Drive
2 Product series
3 Region code
• A: Japan
• B: China
• C: Europe
• T: Asia (Singapore, Taiwan, India, and Korea)
• U: Americas
4 Input power supply voltage
• B: Single-Phase AC 200 V Class
• 2: Three-Phase AC 200 V Class
• 4: Three-Phase AC 400 V Class
5 Rated output current
*1
6 EMC noise filter
• A: No internal EMC filter
• E: Built-in EMC filter
Note:
No internal EMC filter for finless-type drives
7
Enclosure protection design
• B: IP20/UL Open Type
• J: Finless-Type (IP20/UL Open Type)
8 Environmental specification
9 Design revision order
10 Control circuit board
11 Option
12 A: Standard
13 A: Standard
14 Keypad
15 Special applications
*1 Refer to Rated Output Current on page 22 for more information about the rated output current.
■ Rated Output Current
Table 1.2, Table 1.3, and Table 1.4 give the rated output current values.
Note:
• Rated output current values are applicable for drives that operate at standard specifications.
• Derate the output current in applications that:
–Increase the carrier frequency
–Have high ambient temperature
–Install drives side-by-side.
• Use C6-01 [Normal / Heavy Duty Selection] to select Normal Duty rating (ND) or Heavy Duty rating (HD).
Table 1.2 Single-Phase AC 200 V Class
Model
Heavy Duty Rating (HD)
[C6-01 = 0]
(Default)
Normal Duty Rating (ND)
[C6-01 = 1]
Maximum Applicable Motor
Output
kW (HP)
Rated Output Current
A
Maximum Applicable Motor
Output
kW (HP)
Rated Output Current
A
B001 0.1 (1/6) 0.8 0.18 (1/6) 1.2
B002 0.25 (1/4) 1.6 0.37 (1/4) 1.9
B004 0.55 (1/2) 3.0 0.75 (3/4) 3.5
B006 1.1 (1) 5.0 1.1 (1.5) 6.0
B010 1.5 (2) 8.0 2.2 (3) 9.6
B012 2.2 (3) 11.0 3.0 (3) 12.2
B018 4.0 (5) 17.6 - -
