10.8 Drive Exterior and Mounting Dimensions
350 YASKAWA SIEPC71061753C GA500 Technical Manual
Table 10.38 Single-Phase 200 V Class (Finless-Type Drive)
Model
Dimensions mm (in)
Est. Weight
kg (lb)
W H D W1 H1 t1 d
B006
108
(4.25)
128
(5.04)
81
(3.19)
96
(3.78)
118
(4.65)
4
(0.16)
M5
0.9
(1.98)
B010
108
(4.25)
128
(5.04)
92.5
(3.64)
96
(3.78)
118
(4.65)
4
(0.16)
M5
1.0
(2.20)
B012
140
(5.51)
128
(5.04)
98
(3.86)
128
(5.04)
118
(4.65)
4
(0.16)
M5
1.2
(2.65)
Table 10.39 Three-Phase 200 V Class (Finless-Type Drive)
Model
Dimensions mm (in)
Est. Weight
kg (lb)
W H D W1 H1 t1 d
2008
108
(4.25)
128
(5.04)
72.5
(2.85)
96
(3.78)
118
(4.65)
4
(0.16)
M5
0.8
(1.76)
2010
108
(4.25)
128
(5.04)
72.5
(2.85)
96
(3.78)
118
(4.65)
4
(0.16)
M5
0.8
(1.76)
2012
108
(4.25)
128
(5.04)
81
(3.19)
96
(3.78)
118
(4.65)
4
(0.16)
M5
0.9
(1.98)
2018
140
(5.51)
128
(5.04)
78
(3.07)
128
(5.04)
118
(4.65)
4
(0.16)
M5
1.2
(2.65)
2021
140
(5.51)
128
(5.04)
78
(3.07)
128
(5.04)
118
(4.65)
4
(0.16)
M5
1.2
(2.65)
Table 10.40 Three-Phase 400 V Class (Finless-Type Drive)
Model
Dimensions mm (in)
Est. Weight
kg (lb)
W H D W1 H1 t1 d
4001
108
(4.25)
128
(5.04)
75
(2.95)
96
(3.78)
118
(4.65)
4
(0.16)
M5
0.8
(1.76)
4002
108
(4.25)
128
(5.04)
75
(2.95)
96
(3.78)
118
(4.65)
4
(0.16)
M5
0.8
(1.76)
4004
108
(4.25)
128
(5.04)
83.5
(3.29)
96
(3.78)
118
(4.65)
4
(0.16)
M5
0.9
(1.98)
4005
108
(4.25)
128
(5.04)
100
(3.94)
96
(3.78)
118
(4.65)
4
(0.16)
M5
1.0
(2.20)
4007
108
(4.25)
128
(5.04)
100
(3.94)
96
(3.78)
118
(4.65)
4
(0.16)
M5
1.0
(2.20)
4009
108
(4.25)
128
(5.04)
100
(3.94)
96
(3.78)
118
(4.65)
4
(0.16)
M5
1.0
(2.20)
4012
140
(5.51)
128
(5.04)
78
(3.07)
128
(5.04)
118
(4.65)
4
(0.16)
M5
1.2
(2.65)
