2.5 Drive Models and Drive Watt Loss
38 YASKAWA SIEPC71061753C GA500 Technical Manual
Model
The rated output
current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
2018 17.5 2 35 82 117
2021 21 2 52 111 163
2030 30 2 63 240 303
2042 42 2 84 307 391
2056 56 2 109 367 476
2070 70 2 142 534 676
2082
*1
82 2 160 531 691
*1 There is not a finless-type 2082 model.
■ Three-Phase 400 V Class
Table 2.8 Drive Watt Loss (HD, Fc = 2 kHz)
Model
The rated output
current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4001 1.2 2 8 7 15
4002 1.8 2 10 10 20
4004 3.4 2 13 21 34
4005 4.8 2 15 29 44
4007 5.6 2 16 33 49
4009 7.3 2 21 45 66
4012 9.2 2 27 60 87
4018 14.8 2 48 126 174
4023 18 2 53 152 205
4031 24 2 68 191 259
4038 31 2 81 256 337
4044
*1
39 2 109 338 447
4060
*1
45 2 114 328 442
*1 There are not finless-type 4044 or 4060 models.
Table 2.9 Drive Watt Loss (HD, Fc = Default Setting)
Model
The rated output
current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4001 1.2 8 9 11 20
4002 1.8 8 11 16 27
4004 3.4 8 15 31 46
4005 4.8 8 18 42 60
4007 5.6 8 18 49 67
4009 7.3 8 25 65 90
4012 9.2 8 32 85 117
4018 14.8 8 55 166 221
4023 18 8 61 200 261
4031 24 8 79 255 334
4038 31 8 95 338 433
4044
*1
39 8 127 442 569
4060
*1
45 8 135 446 581
*1 There are not finless-type 4044 or 4060 models.
