2.5 Drive Models and Drive Watt Loss
40 YASKAWA SIEPC71061753C GA500 Technical Manual
■ Three-Phase 200 V Class
Table 2.14 Drive Watt Loss (HD, Fc = 2 kHz)
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
2001E 0.8 2 7 4 11
2002E 1.6 2 8 7 15
2004E 3.0 2 12 13 25
2006E 5.0 2 20 22 42
2008E 6.9 2 15 30 45
2010E 8.0 2 18 37 55
2012E 11.0 2 24 49 73
2018E 14.0 2 27 61 88
2021E 17.6 2 37 83 120
2030E 25.0 2 46 163 209
2042E 33.0 2 56 200 256
2056E 47.0 2 78 269 347
2070E 60.0 2 109 411 520
2082E 75.0 2 133 439 572
Table 2.15 Drive Watt Loss (HD, Fc = Default Setting)
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
2001E 1.2 10 7 5 12
2002E 1.9 10 8 8 16
2004E 3.5 10 13 16 29
2006E 6 10 21 27 48
2008E 8 8 16 35 51
2010E 9.6 8 19 43 62
2012E 12.2 8 25 56 81
2018E 17.5 8 31 82 113
2021E 21 8 41 108 149
2030E 30 8 50 187 237
2042E 42 8 61 232 293
2056E 56 8 86 318 404
2070E 70 8 120 473 593
2082E 82 8 149 525 674
Table 2.16 Drive Watt Loss (ND)
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
2001E 1.2 2 8 5 13
2002E 1.9 2 12 9 21
2004E 3.5 2 15 16 31
2006E 6 2 21 25 46
2008E 8 2 19 37 56
2010E 9.6 2 26 51 77
2012E 12.2 2 31 61 92
2018E 17.5 2 36 82 118
2021E 21 2 53 111 164
2030E 30 2 64 240 304
