YASKAWA CIPR-GA50CB001 Technical Manual

Mechanical Installation
2
2.5 Drive Models and Drive Watt Loss
YASKAWA SIEPC71061753C GA500 Technical Manual 41
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
2042E 42 2 85 307 392
2056E 56 2 110 367 477
2070E 70 2 143 534 677
2082E 82 2 161 531 692
■ Three-Phase 400 V Class
Table 2.17 Drive Watt Loss (HD, Fc = 2 kHz)
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4001E 1.2 2 9 7 16
4002E 1.8 2 11 10 21
4004E 3.4 2 15 21 36
4005E 4.8 2 17 29 46
4007E 5.6 2 18 33 51
4009E 7.3 2 24 45 69
4012E 9.2 2 29 60 89
4018E 14.8 2 52 126 178
4023E 18 2 57 152 209
4031E 24 2 73 191 264
4038E 31 2 89 256 345
4044E 39 2 119 338 457
4060E 45 2 128 328 456
Table 2.18 Drive Watt Loss (HD, Fc = Default Setting)
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4001E 1.2 8 10 11 21
4002E 1.8 8 12 16 28
4004E 3.4 8 17 31 48
4005E 4.8 8 20 42 62
4007E 5.6 8 20 49 69
4009E 7.3 8 28 65 93
4012E 9.2 8 34 85 119
4018E 14.8 8 59 166 225
4023E 18 8 65 200 265
4031E 24 8 84 255 339
4038E 31 8 103 338 441
4044E 39 8 137 442 579
4060E 45 8 149 446 595
Table 2.19 Drive Watt Loss (ND)
Model
Rated Output Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
4001E 1.2 2 9 7 16
4002E 2.1 2 14 12 26
4004E 4.1 2 16 24 40
4005E 5.4 2 18 32 50
4007E 7.1 2 23 44 67
4009E 8.9 2 33 58 91
