11.10 H: Terminal Functions
YASKAWA SIEPC71061753C GA500 Technical Manual 401
Setting Value Function Description Ref.
102 !External Reference 1/2
Selection
Sets the drive to use Run command source 1/2 or Reference command source 1/2 when in REMOTE Mode.
ON : b1-01 = [Frequency Reference Selection 1], b1-02 [Run Command Selection 1]
OFF : b1-15 = [Frequency Reference Selection 2], b1-16 [Run Command Selection 2]
646
103 !Multi-Step Speed
Reference 1
Uses a combination of multi-step speed references 1, 2, 3, and 4 (N.C.) to switch d1-01 to d1-16 [Reference 1 to
16].
646
104 !Multi-Step Speed
Reference 2
Uses a combination of multi-step speed references 1, 2, 3, and 4 (N.C.) to switch d1-01 to d1-16 [Reference 1 to
16].
646
105 !Multi-Step Speed
Reference 3
Uses a combination of multi-step speed references 1, 2, 3, and 4 (N.C.) to switch d1-01 to d1-16 [Reference 1 to
16].
646
106 !Jog Reference Selection
Sets the drive to use the JOG Frequency Reference (JOG command) set in d1-17 [Jog Reference]. The JOG
Frequency Reference (JOG command) overrides the d1-01 to d1-16 [References 1 to 16].
646
107 !Accel/Decel Time
Selection 1
Sets the drive to use C1-01, C1-02 [Acceleration/Deceleration Time 1] or C1-03, C1-04 [Acceleration/
Deceleration Time 2].
646
10 A !Accel/Decel Ramp Hold
Momentarily pauses motor acceleration and deceleration when the terminal deactivates, retains the output
frequency that was stored in the drive at the time of the pause, and restarts motor operation.
646
10B !Overheat Alarm (oH2)
Sets the drive to display an oH2 [Drive Overheat Warning] alarm when the input terminal deactivates. The alarm
does not have an effect on drive operation.
646
10C !Analog Terminal Enable
Selection
Enables and disables the terminal selected with the H3-14 [Analog Input Term Enable Select] function.
ON : Input to the terminal selected with H3-14 is disabled
OFF : Input to the terminal selected with H3-14 is enabled
646
10E !ASR Integral Reset
Sets the command to reset the integral value and use PI control or P control for the speed control loop.
ON : PI control
OFF : P control
646
110 !Up Command
Set this function and 111 [! Down Command] together. Sets the Up command and Down command to use the two
push button switches to increase and decrease the drive frequency reference.
ON : Holds the current frequency reference.
OFF : Increases the frequency reference.
646
111 !Down Command
Set this function and 110 [!Up Command] together. Sets the Up command and Down command to use the two push
button switches to increase and decrease the drive frequency reference.
ON : Holds the current frequency reference.
OFF : Decreases the frequency reference.
646
114 !Fault Reset
Sets the command to reset the current fault when the Run command is not active.
Note:
The drive ignores the fault reset command when the Run command is active. Remove the Run command
before you try to reset a fault.
646
116 !Motor 2 Selection
Sets the command for the drive to operate motor 1 or motor 2. Stop the motors before switching.
ON : Operate motor 1
OFF : Operate motor 2
646
118 !Timer Function
Sets the command to start the timer function. Use this setting with H2-xx = 112 [!Timer Output].
646
119 !PID Disable
Sets the command to disable PID control with an external input when b5-01 = 1 to 8 [PID Function Setting =
Enabled].
ON : PID control enabled
OFF : PID control disabled
646
11 A !Accel/Decel Time
Selection 2
Set this function and H1-xx = 107 [!Accel/Decel Time Selection 1] together. Sets the drive to use C1-01 to C1-08
[Acceleration/Deceleration Times 1 to 4].
646
11B !Programming Lockout
Sets the command to prevent parameter changes when the terminal is OFF. You can continue to view parameter
setting values when the terminal is ON [Parameter Write Prohibit].
ON : Parameter Write Prohibit
OFF : Programming Lockout
646
