Parameter List
11
11.21 Defaults by Drive Model and Duty Rating ND/HD
YASKAWA SIEPC71061753C GA500 Technical Manual 467
No.
*1
Name Unit Default
- Drive Model - B001 B002 B004 B006
C6-01
Normal /
Heavy Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 30 31 32 33
E2-11
(E4-11, E5-
02)
Motor Rated
Power
kW 0.1 0.2 0.2 0.4 0.4 0.75 0.75 1.1
L3-06
Stall Prevent
Level during
Run
% 150 120 150 120 150 120 150 120
L3-24
Motor Accel
Time @ Rated
Torque
s 0.178 0.178 0.178 0.178 0.178 0.142 0.142 0.142
L8-02
Overheat
Alarm Level
°C 105 105 105 105 115 115 115 115
L8-09
Output
Ground Fault
Detection
- 0 0 0 0 0 0 0 0
n1-03
Hunting
Prevention
Time Constant
ms 10 10 10 10 10 10 10 10
n3-02
HSB Current
Limit Level
% 150 120 150 120 150 120 150 120
n5-02
Motor Inertia
Acceleration
Time
s 0.178 0.178 0.178 0.142 0.178 0.142 0.142 0.142
*1 Parameters within parentheses are for motor 2.
No.
*1
Name Unit Default
- Drive Model - B010 B012 B018
C6-01
Normal / Heavy
Duty Selection
-
HD ND HD ND HD ND
0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 34 35 37
E2-11
(E4-11, E5-02)
Motor Rated
Power
kW 1.5 2.2 2.2 3.0 3.7 5.5
b3-04
V/f Gain during
Speed Search
% 100 100 100 100 100 100
b3-06
Speed Estimation
Current Level 1
- 0.5 0.5 0.5 0.5 0.5 0.5
b3-08
Speed Estimation
ACR P Gain
- 0.5 0.5 0.5 0.5 0.5 0.5
b3-26
Direction
Determination
Level
- 1000 1000 1000 1000 1000 1000
b8-03
Energy Saving
Filter Time
s 0.5 0.5 0.5 0.5 0.5 0.5
b8-04
Energy Saving
Coefficient Value
- 169.4 156.8 156.8 136.4 122.9 94.75
C6-02
Carrier Frequency
Selection
- 3 7 3 7 3 7
E2-01
(E4-01)
Motor Rated
Current (FLA)
A 6.2 8.5 8.5 11.4 14 19.6
E2-02
(E4-02)
Motor Rated Slip Hz 2.6 2.9 2.9 2.7 2.73 1.5
E2-03
(E4-03)
Motor No-Load
Current
A 2.8 3 3 3.7 4.5 5.1
E2-05
(E4-05)
Motor Line-to-
Line Resistance
Ω 1.997 1.601 1.601 1.034 0.771 0.399
E2-06
(E4-06)
Motor Leakage
Inductance
% 18.5 18.4 18.4 19 19.6 18.2
