YASKAWA CIPR-GA50CB001

11.21 Defaults by Drive Model and Duty Rating ND/HD
476 YASKAWA SIEPC71061753C GA500 Technical Manual
No.
*1
Name Unit Default
- Drive Model - 4007 4009 4012 4018
C6-01
Normal /
Heavy Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 95 96 97 99
E2-11
(E4-11, E5-
02)
Motor Rated
Power
kW 2.2 3.0 3.0 3.7 4.0 5.5 5.5 7.5
E2-10
(E4-10)
Motor Iron
Loss
W 77 105 105 130 130 193 193 263
E5-01
PM Motor
Code
Selection
- FFFF FFFF FFFF FFFF FFFF FFFF FFFF FFFF
L2-02
Power Loss
Ride Through
Time
s 0.5 0.5 0.5 0.5 0.5 0.5 0.8 0.8
L2-03
Minimum
Baseblock
Time
s 0.5 0.5 0.5 0.6 0.6 0.7 0.7 0.8
L2-04
Powerloss V/f
Recovery
Ramp Time
s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L2-05
Undervoltage
Detection Lvl
(Uv1)
- 380 380 380 380 380 380 380 380
L3-02
Stall Prevent
Level during
Accel
% 150 120 150 120 150 120 150 120
L3-06
Stall Prevent
Level during
Run
% 150 120 150 120 150 120 150 120
L3-24
Motor Accel
Time @ Rated
Torque
s 0.145 0.145 0.145 0.154 0.154 0.168 0.168 0.175
L8-02
Overheat
Alarm Level
°C 90 90 115 115 110 110 120 120
L8-09
Output
Ground Fault
Detection
- 0 0 0 0 0 0 0 0
n1-03
Hunting
Prevention
Time Constant
ms 10 10 10 10 10 10 10 10
n3-02
HSB Current
Limit Level
% 150 120 150 120 150 120 150 120
n5-02
Motor Inertia
Acceleration
Time
s 0.145 0.145 0.145 0.154 0.154 0.168 0.168 0.175
*1 Parameters within parentheses are for motor 2.
No.
*1
Name Unit Default
- Drive Model - 4023 4031 4038 4044
C6-01
Normal /
Heavy Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 9A
REV:A: 9C
REV:B: 19C
*2
REV:A: 9D
REV:B: 19D
*2
9E
E2-11
(E4-11, E5-
02)
Motor Rated
Power
kW 7.5 11 11 15 15 18.5 18.5 22
b3-04
V/f Gain
during Speed
Search
% 100 100 100 100 100 100 100 100
b3-06
Speed
Estimation
Current Level
1
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-08
Speed
Estimation
ACR P Gain
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
