Parameter Details
12
12.11 o: Keypad-Related Settings
YASKAWA SIEPC71061753C GA500 Technical Manual 761
Note:
Use o1-36 [LCD Backlight Brightness] to adjust the intensity of the LCD backlight.
0 : OFF
The backlight will automatically turn off after the time set in o1-38 [LCD Backlight Off-Delay] is expired.
When the backlight is off, push a key on the keypad to temporarily turn the backlight on. After the backlight turns
on, it will turn off automatically after the time set in o1-38 is expired.
Note:
When the backlight is off, push a key on the keypad to temporarily turn the backlight on. Push any key to start keypad operation. Push
to turn the backlight on, then push again to enter a Run command to the drive.
1 : ON
The backlight will always be ON.
■ o1-38: LCD Backlight Off-Delay
No.
(Hex.)
Name Description
Default
(Range)
o1-38
(11BB)
RUN
LCD Backlight Off-Delay
Sets the time until the LCD backlight automatically turns off.
60 s
(10 - 300 s)
When o1-37 = 0 [LCD Backlight ON/OFF Selection= OFF], the backlight will automatically turn off after the
time set in o1-38 expires.
When the backlight is off, push a key on the keypad to temporarily turn the backlight on. After the backlight turns
on, it will turn off automatically after the time set in o1-38 is expired.
■ o1-39: Show Initial Setup Screen
No.
(Hex.)
Name Description
Default
(Range)
o1-39
(11BC)
RUN
Show Initial Setup Screen
Sets the function to show the LCD keypad initial setup screen each time you energize the drive.
This parameter is only available with an LCD keypad.
1
(0, 1)
The initial setup screen shows a menu where you can select the display language, set the date, time, and other
basic settings. When you set this parameter to 0, the drive will not show this screen each time you energize the
drive.
0 : No
The drive will not show the initial setup display screen each time you energize the drive. The drive will show the
Home screen.
1 : Yes
When you input the Run command before you energize the drive or when the you turn on the Run command while
the drive shows the initial setup screen, the drive will replace the initial setup screen with the Home screen.
■ o1-40: Home Screen Display Selection
No.
(Hex.)
Name Description
Default
(Range)
o1-40
(11BD)
RUN
Home Screen Display
Selection
Sets the monitor display mode for the Home screen. This parameter is only available with an LCD
keypad.
0
(0 - 3)
0 : Custom Monitor
1 : Bar Graph
2 : Analog Gauge
3 : Trend Plot
To Next Page
