YASKAWA GA500 GA50U Series

Parameter List
1
1.21 Defaults by Drive Model and Duty Rating ND/HD
YASKAWA TOEPYAIGA5002A GA500 DRIVE PROGRAMMING 141
No.
*1
Name Unit Default
- Drive Model - 4023 4031 4038 4044
C6-01
Normal /
Heavy Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 9A
REV:A: 9C
REV:B: 19C
*2
REV:A: 9D
REV:B: 19D
*2
9E
E2-11
(E4-11, E5-
02)
Motor Rated
Power
kW 7.5 11 11 15 15 18.5 18.5 22
E2-03
(E4-03)
Motor No-
Load Current
A 4 5.6 5.6 7.6 7.6 7.8 7.8 9.2
E2-05
(E4-05)
Motor Line-to-
Line
Resistance
Ω 1.152 0.922 0.922 0.55 0.55 0.403 0.403 0.316
E2-06
(E4-06)
Motor
Leakage
Inductance
% 15.5 19.6 19.6 17.2 17.2 20.1 20.1 23.5
E2-10
(E4-10)
Motor Iron
Loss
W 263 385 385 440 440 508 508 586
E5-01
PM Motor
Code Selection
- FFFF FFFF FFFF FFFF FFFF FFFF FFFF FFFF
L2-02
Power Loss
Ride Through
Time
s 1 1 2 2 2 2 2 2
L2-03
Minimum
Baseblock
Time
s 0.8 0.9 0.9 1 1 1 1 1
L2-04
Powerloss V/f
Recovery
Ramp Time
s 0.3 0.3 0.3 0.6 0.6 0.6 0.6 0.6
L2-05
Undervoltage
Detection Lvl
(Uv1)
- 380 380 380 380 380 380 380 380
L3-02
Stall Prevent
Level during
Accel
% 150 120 150 120 150 120 150 120
L3-06
Stall Prevent
Level during
Run
% 150 120 150 120 150 120 150 120
L3-24
Motor Accel
Time @ Rated
Torque
s 0.175 0.265 0.265 0.244 0.244 0.317 0.317 0.355
L8-02
Overheat
Alarm Level
°C 120 120 120 120 120 120 125 125
L8-09
Output Ground
Fault
Detection
- 0 0 1 1 1 1 1 1
n1-03
Hunting
Prevention
Time Constant
ms 10 10 10 10 10 10 10 10
n3-02
HSB Current
Limit Level
% 150 120 150 120 150 120 150 120
n5-02
Motor Inertia
Acceleration
Time
s 0.175 0.265 0.265 0.244 0.244 0.317 0.317 0.355
*1 Parameters within parentheses are for motor 2.
*2 The value is different for different drive hardware revisions. The “REV” column on the nameplate on the right side of the drive identifies
the hardware revision.
