4 Receiving
10 YASKAWA TOEPC71061737B GA800 Drive Installation & Primary Operation
No. Description
5 EMC noise filter
A: No built-in EMC filter
6 Protection design
B: IP20/UL Open Type
W: IP55/UL Type 12 Heatsink External Mounting
7 Environmental specification
M: Resistant to dust/humidity
■ Rated Output Current
Table 4.2 to Table 4.3 give the rated output current values.
Note:
• These output current values apply to drives that operate at standard specifications.
• Derate the output current for applications that require:
–Higher carrier frequencies
–Ambient temperature beyond nameplate ratings
–Drives installed side-by-side.
• Use C6-01 [Normal / Heavy Duty Selection] to select Normal Duty rating (ND) or Heavy Duty rating (HD).
Table 4.2 Three-Phase AC 200 V Class
Model
Heavy Duty Rating (HD)
Parameter C6-01 = 0
Normal Duty Rating (ND)
Parameter C6-01 = 1 (Default)
Maximum Applicable Motor
Output
kW (HP)
Rated Output Current
A
Maximum Applicable Motor
Output
kW (HP)
Rated Output Current
A
2004
0.55 (3/4) 3.5 0.75 (1) 4.2
2006
0.75 (1) 5 1.1 (1 1/2) 6
2008
1.1 (1 1/2) 6.9 1.5 (2) 8
2010
1.5 (2) 8 2.2 (3) 9.6
2012
2.2 (3) 11 3 (4) 12.2
2018
3 (4) 14 3.7 (5) 17.5
2021
3.7 (5) 17.5 5.5 (7 1/2) 21
2030
5.5 (7 1/2) 25 7.5 (10) 30
2042
7.5 (10) 33 11 (15) 42
2056
11 (15) 47 15 (20) 56
2070
15 (20) 60 18.5 (25) 70
2082
18.5 (25) 75 22 (30) 82
2110
22 (30) 88 30 (40) 110
2138
30 (40) 115 37 (50) 138
2169
37 (50) 145 45 (60) 169
2211
45 (60) 180 55 (75) 211
2257
55 (75) 215 75 (100) 257
2313
75 (100) 283 90 (125) 313
2360
90 (125) 346 110 (150) 360
2415
110 (150) 415
110 (150) 415
