13 European Standards
YASKAWA TOEPC71061737B GA800 Drive Installation & Primary Operation 99
WARNING
Electrical Shock Hazard. After the drive blows a fuse or trips a GFCI, do not immediately energize the drive or
operate peripheral devices. Wait for the time specified on the warning label at a minimum and make sure that all indicators are OFF.
Then check the wiring and peripheral device ratings to find the cause of the problem. If you do not know the cause of the problem,
contact Yaskawa before you energize the drive or peripheral devices. If you do not fix the problem before you operate the drive or
peripheral devices, it can cause serious injury or death.
Table 13.2 Factory-Recommended Branch Circuit Protection (200 V Class)
Drive Model
Semiconductor Protection Fuse
Rated Current
Manufacturer: EATON/Bussmann
2004 FWH-45B
2006 FWH-45B
2008 FWH-45B
2010 FWH-45B
2012 FWH-50B
2018 FWH-80B
2021 FWH-80B
2030 FWH-125B
2042 FWH-150B
2056 FWH-200B
2070 FWH-225A
Drive Model
Semiconductor Protection Fuse
Rated Current
Manufacturer: EATON/Bussmann
2082
FWH-225A
FWH-250A
*1
2110
FWH-225A
FWH-250A
*1
2138
FWH-275A
FWH-300A
*1
2169
FWH-275A
FWH-350A
*1
2211
FWH-325A
FWH-450A
*1
2257 FWH-600A
2313 FWH-800A
2360 FWH-1000A
2415 FWH-1000A
*1 Yaskawa recommends a fuse with a large rated current for applications with repeated loads.
Table 13.3 Factory-Recommended Branch Circuit Protection (400 V Class)
Drive Model
Semiconductor Protection Fuse
Rated Current
Manufacturer: EATON/Bussmann
4002 FWH-50B
4004 FWH-50B
4005 FWH-50B
4007 FWH-60B
4009 FWH-60B
4012 FWH-60B
4018 FWH-80B
4023 FWH-90B
4031 FWH-150B
4038 FWH-200B
4044 FWH-200B
4060 FWH-225A
4075 FWH-250A
4089 FWH-275A
Drive Model
Semiconductor Protection Fuse
Rated Current
Manufacturer: EATON/Bussmann
4103 FWH-275A
4140 FWH-300A
4168
FWH-325A
FWH-400A
*1
4208 FWH-500A
4250 FWH-600A
4302 FWH-700A
4371 FWH-800A
4414 FWH-1000A
4477 FWH-1200A
4568 FWH-1200A
4605
FWH-1400A
FWH-1600A
*1
4720
FWH-1400A
FWH-1600A
*1
*1 Yaskawa recommends a fuse with a large rated current for applications with repeated loads.
■ CE Standards Compliance for DC Power Supply Input
To comply with CE Standards, install a fuse for the DC power supply input.
Figure 13.3 shows a wiring example for a DC power supply that has two drives connected in parallel.

YASKAWA GA800 Series Specifications

General

Series	GA800
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication	Ethernet/IP, Modbus RTU/TCP, PROFIBUS, PROFINET, DeviceNet
Safety	STO (Safe Torque Off)
Enclosure	IP00, IP20, IP55
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Ground Fault, Short Circuit
Enclosure Rating	IP00, IP20, IP55
Voltage Class	200V, 400V
