Page #77 background imageLoading...
Page #77 background image
12 UL Standards
YASKAWA TOEPC71061737B GA800 Drive Installation & Primary Operation 77
Model
Recommended Gauge (AWG, kcmil)
Crimp Terminal Part
Number
*1
R/L1
S/L2
T/L3
U/T1
V/T2
W/T3
-, +1 +3
4720
- - - - 2/0 S2/0-12R-X
- - - 4/0 × 4P - S4/0-12R-5
300 × 4P 300 × 4P - - -
LCA300-12-X
LCAX300-12-6
- - 400 × 4P - - LCA400-12-6
*1 For use with PANDUIT Corp. heat-shrinkable tubing HSTT series or an equivalent UL recognized heat-shrinkable tubing rated 600 V
minimum.
Factory-Recommended Branch Circuit Protection for UL Listing
Yaskawa recommends that you install one of these types of branch circuit protection to comply with UL 508C.
Semiconductor protective type fuses are recommended, but the tables also show alternative branch circuit protection
devices. Maximum Time Delay fuse is 175% of drive full load output amps (FLA). This includes all Class CC, J, or T
class fuses. Refer to Table 12.2 to Table 12.3 for the recommended fuses.
WARNING
Electrical Shock Hazard. After the drive blows a fuse or trips a GFCI, do not immediately energize the drive or
operate peripheral devices. Wait for the time specified on the warning label at a minimum and make sure that all indicators are OFF.
Then check the wiring and peripheral device ratings to find the cause of the problem. If you do not know the cause of the problem,
contact Yaskawa before you energize the drive or peripheral devices. If you do not fix the problem before you operate the drive or
peripheral devices, it can cause serious injury or death.
200 V class
Use the fuses specified in this document to prepare the drive for use on a circuit that supplies not more than 100,000
RMS and not more than 240 Vac when there is a short circuit in the power supply.
400 V class
Use the fuses specified in this document to prepare the drive for use on a circuit that supplies not more than 100,000
RMS and not more than 480 Vac when there is a short circuit in the power supply.
The user must provide branch circuit protection to protect input branch circuits as specified by the National Electric
Code (NEC), the Canadian Electric Code, Part I (CEC), and local codes.
200 V Class
Table 12.2 Factory Recommended Fuses for 200 V Class
Drive Model
Semiconductor Fuse
Manufacturer: EATON/Bussmann
Alternate Time-Delay
Class CC, J, or T
*1
Maximum Amp Rating
(Maximum SCCR (kA))
2004 FWH-45B 6 (65)
2006 FWH-45B 10 (65)
2008 FWH-45B 12 (65)
2010 FWH-45B 15 (65)
2012
FWH-50B
FWH-80B
*2
20 (65)
2018
FWH-80B
FWH-100B
*2
30 (65)
2021
FWH-80B
FWH-100B
*2
35 (65)
2030 FWH-125B 50 (100)
2042 FWH-200B 70 (100)
2056 FWH-225A 90 (100)
2070 FWH-250A 110 (100)
