User Constant Tables
5-13
DC Injection Braking: b2
b1-12
HAND Fref
Source
Sets the source of frequency refer-
ence for HAND operation.
0: Digital Operator
1: Control Circuit Terminal (ana-
log input)
0 or 1 0 No A 0IE0 –
Con-
stant
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
Page
b2-01
DC injection
braking starting
frequency
Used to set the frequency at which
DC injection braking starts in units
of Hz when b1-03 is set to 0 (decel-
eration to stop).
When b2-01 is less than E1-09, E1-
09 becomes the DC injection brak-
ing starting frequency.
0.0 to
10.0
0.5 Hz No A 189H 6-11
b2-02
DC injection
braking current
Sets the DC injection braking cur-
rent as a percentage of the inverter
rated current.
0 to
100
50% No A 18AH
6-11
6-14
b2-03
DC injection
braking time at
start
Used to set the time to perform DC
injection braking at start in units of
1 second.
Used to stop coasting motor and
restart it. When the set value is 0,
DC injection braking at start is not
performed.
0.00
to
10.00
0.00 s No A 18BH 6-14
b2-04
DC injection
braking time at
stop
Used to set the time to perform DC
injection braking at stop in units of
1 second.
Used to prevent coasting after the
stop command is input. When the
set value is 0.00, DC injection brak-
ing at stop is not performed.
0.00
to
10.00
0.50 s No A 18CH 6-11
b2-09
Motor pre-heat
current
Sets the DC current level when the
motor pre-heat function is enabled
using a digital input.
0 to 100 0% No A IE1H 6-14
Con-
stant
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
Page
