Digital Operation Display Functions and Levels
5-5
b5-02
Proportional
gain (P)
Sets P-control proportional gain.
P-control is not performed when the set-
ting is 0.00.
0.00
to
25.00
1.00 Yes A 1A6H
b5-03 Integral (I) time
Sets I-control integral time in 1-second
units.
I-control is not performed when the set-
ting is 0.0.
0.0 to
360.0
1.0 s Yes A 1A7H
b5-04 Integral (I) limit
Sets the I-control limit as a percentage of
the maximum output frequency.
0.0 to
100.0
100.0% Yes A 1A8H
b5-06 PI limit
Sets the limit after PI-control as a percent-
age of the maximum output frequency.
0.0 to
100.0
100.0% Yes A 1AAH
b5-07
PI offset adjust-
ment
Sets the offset after PI-control as a per-
centage of the maximum output fre-
quency.
-100.0
to
+100.0
0.0% Yes A 1ABH
b5-08
PI delay time
constant
Sets the time constant for low pass filter
for PI-control outputs in 1-second units.
Usually not necessary to set.
0.00 to
10.00
0.00 s Yes A 1ACH
b5-09
PI output char-
acteristics selec-
tion
Selects forward/reverse direction for PI
output.
0: PI output is forward.
1: PI output is reverse
0 or 1 0 No A 1ADH
b5-10 PI output gain Sets output gain.
0.0 to
25.0
1.0 No A 1AEH
b5-11
PI reverse output
selection
0: Limit to 0 when PI output is negative.
1: Reverses when PI output is negative.
Limit to 0 is also active when reverse pro-
hibit is selected by
b1-04.
0 or 1 0 No A 1AFH
b5-12
Selection of PI
feedback signal
loss detection
0: No detection of PI feedback loss.
1: Detection of PI feedback loss.
Operation continues during detection,
the fault contact is not operated.
2: Detection of PI feedback loss.
The motor coasts to stop at detection,
and the fault contact operates.
0 to 2 0 No A 1B0H
b5-13
PI feedback loss
detection level
Sets the PI feedback loss detection level
as percentage using the maximum output
frequency as 100%.
0 to 100 0% No A 1B1H
b5-14
PI feedback loss
detection time
Sets the PI feedback loss detection time.
0.0 to
25.5
1.0 s No A 1B2H
b5-15
Sleep function
operation level
Sets the sleep function start level as a fre-
quency.
0.0 to
200.0
0.0 Hz No A 1B3H
b5-16
Sleep operation
delay time
Sets the delay time until the sleep function
starts.
0.0 to
25.5
0.0 s No A 1B4H
b5-17
Accel/decel time
for PI reference
Sets the accel/decel time for the PI Soft-
starter (SFS).
0.0 to
25.5
0.0 s No A 1B5H
b5-18
PI Setpoint
Selection
0: Disabled
1: Enabled
0 to 1 0 No A 1DCH
b5-19 PI Setpoint PI-target value
0.00 to
100.00
%
0 Yes A 1DDH
Con-
stant
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Regis-
ter
