* 1. The setting range for acceleration/deceleration times depends on the setting of C1-10 (Acceleration/deceleration Time Setting Unit). If C1-10 is set to 0,
the setting range is 0.00 to 600.00 (s).
* 2. The factory settings depend on the Inverter capacity. The values for a 200 V Class Inverter for 0.4 kW are given.
* 3. These are values for a 200 V Class Inverter. Values for a 400 V Class Inverter are double.
* 4. The factory setting will change when the control method is changed. The open-loop vector 1 factory settings are given.
* 5. E1-13 is set to the same value as E1-05 by autotuning.
* 6. The setting range is from 10% to 200% of the Inverter rated output current. The value for a 200 V Class Inverter for 0.4 kW is given.
For the motor no-load current, set E2-03 to a value less than that of E2-01.
H4-02
Gain (ter-
minal FM)
Set the voltage level gain for multi-
function analog output 1.
Set the number of multiples of 10 V to
be output as the 100% output for the
monitor items. Voltage output from the
terminals, however, have a 10 V max.
A meter calibration function is avail-
able.
*12
0.00 to
2.50
1.00YesQQQQQ41EH
Terminal
FM Gain
H4-05
Gain (ter-
minal AM)
Set the voltage level gain for multi-
function analog output 2.
Set the number of multiples of 10 V to
be output as the 100% output for the
monitor items. Voltage output from the
terminals, however, have a 10 V max.
A meter calibration function is avail-
able.
*12
0.00 to
2.50
0.50YesQQQQQ421H
Terminal
AM Gain
L1-01
Motor
protection
selection
Set to enable or disable the motor
overload protection function using the
electronic thermal relay.
0: Disabled
1: General-purpose motor protection
2: Inverter motor protection
3: Vector motor protection
In some applications when the
Inverter power supply is turned off,
the thermal value is reset, so even if
this constant is set to 1, protection
may not be effective.
When several motors are connected to
one Inverter, set to 0 and ensure that
each motor is installed with a protec-
tion device.
0 to 3 1 NoQQQQQ480H
MOL Fault
Select
L3-04
Stall pre-
vention
selection
during
decelera-
tion
0: Disabled (Deceleration as set. If
deceleration time is too short, a
main circuit overvoltage may
result.)
1: Enabled (Deceleration is stopped
when the main circuit voltage
exceeds the overvoltage level.
Deceleration restarts when voltage
is returned.)
2: Intelligent deceleration mode
(Deceleration rate is automatically
adjusted so that the Inverter can
decelerate in the shortest possible
time. Set deceleration time is
disregarded.)
3: Enabled (with Braking Resistor
Unit)
When a braking option (Braking
Resistor, Braking Resistor Unit, Brak-
ing Unit) is used, always set to 0 or 3.
0 to 3
*9
1 NoQQQQQ492H
StallP
Decel Sel
Con-
stant
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Regis-
ter
Display
V/f
V/f
with
PG
Open
-loop
Vec-
tor
1
Flux
Vec-
tor
Open
Loop
Vec-
tor
2
