User Constant Tables
5- 49
* If the multi-function input is set to 79 and the input value is “closed,” operation will be performed with a speed specification of 0.
16 Motor switch command (Motor 2 selection) Yes Yes Yes Yes Yes –
17
Emergency stop (Normally closed condition: Deceleration to stop in deceleration
time set in C1-09 when OFF)
Yes Yes Yes Yes Yes 6-1 7
18
Timer function input (Functions are set in b4-01 and b4-02 and the timer function
outputs are set in H1- and H2-.)
Yes Yes Yes Yes Yes 6-107
19 PID control disable (ON: PID control disabled) Yes Yes Yes Yes Yes
6-111
1A Accel/Decel time 2 Yes Yes Yes Yes Yes 6-19
1B
Constants write enable (ON: All constants can be written-in. OFF: All constants
are write protected.)
Yes Yes Yes Yes Yes
6-158
7-26
1C
Trim control increase (ON: d4-02 frequency is added to analog frequency refer-
ence.)
Yes Yes Yes Yes Yes 6-8 3
1D
Trim control decrease (ON: d4-02 frequency is subtracted from analog frequency
reference.)
Yes Yes Yes Yes Yes 6-8 3
1E Analog frequency reference sample/hold Yes Yes Yes Yes Yes 6-84
20 to
2F
External fault (Desired settings possible)
Input mode: NO contact/NC contact, Detection mode: Normal/during operation
Yes Yes Yes Yes Yes 6-8 6
30
PID control integral reset (While the input terminal is closed, the PID control
integral value is reset to 0 and maintained at that value.)
Yes Yes Yes Yes Yes
6-111
31 PID control integral hold (ON: Hold) Yes Yes Yes Yes Yes
6-111
32 Multi-step speed reference 4 Yes Yes Yes Yes Yes –
34 PID soft starter ON/OFF Yes Yes Yes Yes Yes
6-111
35 PID input characteristics switch Yes Yes Yes Yes Yes
6-111
60 DC injection braking command (ON: Performs DC injection braking) Yes Yes Yes Yes Yes 6-16
61 External search command 1 (ON: Speed search from maximum output frequency) Yes No Yes No Yes 6-68
62 External search command 2 (ON: Speed search from set frequency) Yes No Yes No Yes 6-68
63
Field weakening command (ON: Field weakening control set for d6-01 and d6-
02)
Yes Yes No No No –
64 External speed search command 3 (NC contact) Yes Yes Yes Yes Yes –
65 KEB (deceleration at momentary power loss) command (NC contact) Yes Yes Yes Yes Yes –
66 KEB (deceleration at momentary power loss) command (NO contact) Yes Yes Yes Yes Yes –
67
Communications test mode (“Pass” is displayed when the communications test is
passed.)
Yes Yes Yes Yes Yes 6-106
68 High-slip braking (HSB) Yes Yes No No No –
71 Speed/torque control change (ON: Torque control) No No No Yes Yes
6-131
6-137
72 Zero-servo command (ON: Zero-servo) No No No Yes No 6-148
77 Speed control (ASR) proportional gain switch (ON: C5-03) No No No Yes Yes 6-139
78 Polarity reversing command for external torque reference No No No Yes Yes 6-131
79
Brake ON signal (Brake Signal)
*
No No No No Yes –
Set-
ting
Value
Function
Control Methods
Page
V/f
V/f
with
PG
Open
Loop
Vec-
tor
1
Flux
Vec-
tor
Open
Loop
Vec-
tor
2
