YASKAWA Varispeed G7 Series User Manual

User Constants
10- 37
10
Table 10.9 User Constants (Continued)
F4-03 Channel 2 monitor selection 3
F4-04 Channel 2 gain 0.50
F4-05 Channel 1 output monitor bias 0.0
F4-06 Channel 2 output monitor bias 0.0
F4-07
Analog output signal level for
channel 1
0
F4-08
Analog output signal level for
channel 2
0
F5-01 Channel 1 output selection 0
F5-02 Channel 2 output selection 1
F5-03 Channel 3 output selection 2
F5-04 Channel 4 output selection 4
F5-05 Channel 5 output selection 6
F5-06 Channel 6 output selection 37
F5-07 Channel 7 output selection 0F
F5-08 Channel 8 output selection 0F
F5-09 DO-08 output mode selection 0
F6-01
Operation selection after commu-
nications error
1
F6-02
Input level of external fault from
Communications Option Board
0
F6-03
Stopping method for external fault
from Communications Option
Board
1
F6-04
Trace sampling from Communica-
tions Option Board
0
F6-06
Torque reference/torque limit
selection from optical option
0
F6-08
∗13
Operation selection after SI-T
WDT error
1
F6-09
∗13
Number of SI-T BUS error detec-
tion
2
H1-01 Terminal S3 function selection 24
H1-02 Terminal S4 function selection 14
No. Name
Fac-
tory
Setting
Set-
ting
H1-03 Terminal S5 function selection
3 (0)
*14
H1-04 Terminal S6 function selection
4 (3)
*14
H1-05 Terminal S7 function selection
6 (4)
*14
H1-06 Terminal S8 function selection
8 (6)
*14
H1-07 Terminal S9 function selection 5
H1-08 Terminal S10 function selection 32
H1-09 Terminal S11 function selection 7
H1-10 Terminal S12 function selection 15
H2-01
Terminal M1-M2 function selec-
tion (contact)
0
H2-02
Terminal P1 function selection
(open collector)
1
H2-03
Terminal P2 function selection
(open collector)
2
H2-04
Terminal P3 function selection
(open-collector)
6
H2-05
Terminal P4 function selection
(open-collector)
10
H3-01
Signal level selection (terminal
A1)
0
H3-02 Gain (terminal A1) 100.0
H3-03 Bias (terminal A1) 0.0
H3-04
Signal level selection (terminal
A3)
0
H3-05
Multi-function analog input (termi-
nal A3) function selection
2
H3-06 Gain (terminal A3) 100.0
H3-07 Bias (terminal A3) 0.0
H3-08
Signal level selection (terminal
A2)
2
H3-09
Multi-function analog input (termi-
nal A2) function selection
0
H3-10 Gain (terminal A2) 100.0
H3-11 Bias (terminal A2) 0.0
H3-12 Analog input filter time constant 0.03
No. Name
Fac-
tory
Setting
Set-
ting
TOE-S616-60.1.book 37 ページ ２０１７年８月４日 金曜日 午後３時４１分
