LOCAL/REMOTE Selection (Setting: 17)
Select the operation reference from either the Digital Operator or from
the settings of the RUN Command Selection (n003) and Frequency Ref-
erence Selection (n004). The LOCAL/REMOTE Selection can be used
only when stopped.
Open: Run according to the setting of RUN Command Selection
(n003) or Frequency Reference Selection (n004).
Closed: Run according to the frequency reference and RUN command
from the Digital Operator.
Example: Set n003=1, n004=7, n008=0.
Open: Run according to the frequency reference from Digital Opera-
tor terminal CN2-1 and RUN command from multi-function
input terminals S1 to S7.
Closed: Run according to the potentiometer frequency reference and
RUN command from the Digital Operator.
UP/DOWN Commands (Setting: n053 = 034)
When the FWD (REV) RUN command is ON, acceleration/deceleration
is enabled by inputting the UP or DOWN signal from multi-function
input terminals S3 and S4 without changing the frequency reference.
Operation can thus be performed at the desired speed. When UP/
DOWN commands are specified in n053, any function set in n052 is
disabled, terminal S3 is the input terminal for the UP command, and ter-
minal S4 is the input terminal for the DOWN command.
Note: Terminals S5 through S7 can be used only from DeviceNet communica-
tions. There are no corresponding external terminals.
Multi-function Input Termi-
nal S3 (UP command)
Closed Open Open Closed
Multi-function Input Termi-
nal S4 (DOWN command)
Open Closed Open Closed
Operation Status Accele
ration
Decele
ration
Hold Hold
