YASKAWA Varispeed V7 - Page 23

22
Varispeed V7 Inverters with the Covers Removed
Example for 3-phase (200 V Class, 1.5 kW) Inverter
Example for 3-phase (200 V Class, 0.1 kW) Inverter
Frequency Setting Potentiometer
Inverter Operation
Status Indicators
Baud Rate Setting Switch
Jumper Bar
Ground Terminals
Main Circuit Terminal Block
Control Circuit Terminal Block
Input Polarity Switch
Frequency Setting Potentiometer
Inverter Operation
Status Indicators
Baud Rate Setting
Switch
Jumper Bar
Ground Terminals
Main Circuit Terminal Block
Control Circuit Terminal Block
Input Polarity Switch
MAC ID Setting Switches
DeviceNet Terminal Block
MAC ID Setting Switches
DeviceNet Terminal Block
