2. Identifying the Parts
23
Main Circuit Terminal Arrangement
The terminal arrangement of the main circuit terminals depends on the
Inverter model.
CIMR-V7 20P1 to 20P7, B0P1 to B0P4
CIMR-V7 21P5, 22P2, B0P7, B1P5, 40P2 to 42P2
CIMR-V7 24P0, B2P2, 43P0, 43P7
CIMR-V7 B3P7
CIMR-V7 25P5, 27P5, 45P5, 47P5
