Assembly Object (Class 04 Hex)
The Assembly object is the object related to the I/O message function.
The I/O message function is configured by this object for communica-
tions.
• Supported Services
01 01 MAC ID Indicates the set-
ting for the MAC
ID. The MAC ID
can be set with the
rotary switches or
constant n150.
0 to
63
00 OK --- Byte
02 Baud
Rate
Indicates the set-
ting for the baud
rate. The baud
rate can be set
with the rotary
switches or con-
stant n150.
• 0: 125 kbps
• 1: 250 kbps
• 2: 500 kbps
0 to 2 00 OK --- Byte
05 Alloca-
tion In-
forma-
tion
Indicates the De-
viceNet communi-
cations connection
information.
--- 00,00 OK --- Byte
x 2
Service
Code
(Hex)
Service Name Description
0E Get_Attribute_
Single
Returns the contents of the specified
attribute.
10 Set_Attribute_
Single
Changes the contents of the speci-
fied attribute.
In-
stance
At-
tribute
Name Contents Setting
Range
Factory Set-
ting (Hex)
Read Write Size
