Yealink SIP-T54S User Manual

User Guide for the SIP-T54S Media IP Phone
94
The following table lists the page icons to indicate different statuses:
Icons
Description
Fast-flashing: the BLF monitored user receives an incoming call
on the non-current page.
Solid: there is a parked call on the non-current page.
Fast-flashing: the line receives an incoming call on the
non-current page.
For more information on the page switch key LED status, refer to LED Instructions on page 10.
To configure the page icon to indicate status via web user interface:
1. Click on Dsskey->Line Key.
2. Select Enabled from the pull-down list of Enable Page Tips.
3. Click Confirm to accept the change.
Note
Label Length
You can specify labels for some key features, which will be displayed on the idle LCD screen. If
the length of the label exceeds the maximum display length, the phone will only display the first
few characters. You can configure the phone to display more characters via label length feature.
Page Tips features is configurable via web user interface only.

Yealink SIP-T54S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Wall mountable	Yes
Wi-Fi	-
Bluetooth version	2.1+EDR
Ethernet LAN interface type	Gigabit Ethernet
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
AC adapter input voltage	100 - 240 V
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Voice codecs	G.722, G.723, G.723.1, G.726, G.729B, OPUS, iLBC
Front camera	No
Volume control	Digital
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Operating system installed	Linux

Weight and Dimensions

Depth	218.8 mm
Width	233 mm
Height	172.6 mm
