Getting Started
5
2. Insert the batteries in the correct polarity.
3. Close the battery cover.
Battery Information
Technology: Nickel Metal Hydride (NiMH)
Size: AAA
Voltage: 1.2V
Capacity: 800mAh
We strongly recommend you use the batteries complying with the above parameters.
Because the compliant ones can guarantee the specified operating time, full
functionality and long service life. The operating time of your handset depends on the
capacity and age of the batteries and the way they are used.
We recommend the following battery types:
Sanyo NiMH 800
GP 850 mAh
Yuasa Technologies AAA 800
The device is supplied with two recommended batteries.
1. Connect the DC plug on the power adapter to the DC5V port on the charger cradle.
2. Connect the other end of the power adapter into an electrical power outlet.
