8-8
IM CA71-E
SD Sets sourced setpoint/queries the current setting.
When normal
condition
Syntax for setting
SDm<delimiter>
Syntax for query
SD?<delimiter> Response: SDm<delimiter>
Description of parameter
m: Sourced setpoint (7 digits) ex. +1.0000
SF Queries the source function.
When normal
condition
Syntax for query
SF? <delimiter> Response: SFm<delimiter>
Description of parameter
m: Function
m=0: 30V m=1: 10V m=2: 1V m=3: 100mV
m=4: Resistance m=5: Pulse m=6: 20mA m=7: 4 to 20mA
m=8: 20mASINK
SO On/Off of source output/queries the current setting.
When normal
condition/adjustment
Syntax for setting
SOm<delimiter>
Syntax for query
SO? <delimiter>
Response: SOm<delimiter>
Description of parameter
m: Condition of generation (source)
m=0: Off m=1: On
SR
Sets
the
sourcing
range/queries
the
current
setting.
When normal
condition/adjustment
Syntax for setting
SRm<delimiter>
Syntax for query
SR?<delimiter> Response: SRm<delimiter>
Description of parameter
m: sourcing range
[100mV] (When normal condition)
m=0: DC 100mV m=1: TcK m=2: TcE
m=3: TcJ m=4: TcT m=5: TcR
m=6: TcB m=7: TcS m=8: TcN
m=9: TcL m=10: TcU
[100mV] (When adjustment)
m=0: DC 100mV m=1: TcK
[] m=0: 400 m=1: Pt100 m=2: JPt
[Freq ] m=0: 500Hz m=1: 1kHz m=2: 10kHz
8.7 Detailed Description of Commands
