YOKOGAWA Centum VP User Manual

3. Cabling
3-64
TI 33J01J10-01EN
3.6.3 Connecting Signal Cables with FIO
n Pressure Clamp Terminal
CH1
CH2
CH16
Example of Analog module AAI141
Signal cable
F030602.ai
NC (not connected)
Figure I/O Module with Pressure Clamp Terminal
n Dual-redundant Pressure Clamp Terminal
CH1
CH2
CH16
Example of Analog module AAI141
NC (not connected)
Signal cable
F030603.ai
Figure I/O Module with Dual-redundant Pressure Clamp Terminal
Oct. 5, 2018-00

YOKOGAWA Centum VP Specifications

General

System Type	Distributed Control System (DCS)
Architecture	Client-Server
Control Network	Vnet/IP
Controller Type	FCS (Field Control Station)
Programming Languages	Function Block Diagram (FBD), Sequential Function Chart (SFC), Ladder Diagram (LD), Structured Text (ST)
Operating System	Real-time OS (for Controllers)
Redundancy	Controller, Communication Network, Power Supply
I/O Modules	Analog I/O, Digital I/O
Communication Protocols	Modbus, OPC, Foundation Fieldbus, Profibus, HART
Scalability	From small to large applications
Security	User Authentication, Authorization, Audit Trail
Integration Capabilities	OPC UA, Modbus, Ethernet/IP
