3. Cabling
3-70
TI 33J01J10-01EN
n Connecting Relay Board with Digital I/O Module

ADV551 is shown below.
CN1
F030611.ai
Connection with FG
ADV551+ATD5A adaptor
Yokogawa-specific cable AKB331
ARM55D
Figure Example of Relay Board Connection with Digital I/O Module
Oct. 5, 2018-00
