:CURSor[:TY]:MARKer:M<x>:TRACe
Function Sets or queries the source waveform that you
want to measure using the marker cursors.
Syntax
:CURSor[:TY]:MARKer:M<x>:TRACe {<NRf>
|MATH<y>|OFF}
:CURSor[:TY]:MARKer:M<x>:TRACe?
<x> = 1 to 4
<NRf> = 1 to 4 (1 or 2 for 2-channel models)
<y> = 1 or 2 (1 only for 2-channel models)
Example
:CURSOR:TY:MARKER:M1:TRACE 1
:CURSOR:TY:MARKER:M1:TRACE?
-> :CURSOR:TY:MARKER:M1:TRACE 1
:CURSor[:TY]:MARKer:M<x>:V?
Function Queries all vertical axis settings for a marker
cursor.
Syntax
:CURSor[:TY]:MARKer:M<x>:V?
<x> = 1 to 4
:CURSor[:TY]:MARKer:M<x>:V:STATe
Function Sets or queries the on/off status of the vertical
value of a marker cursor.
Syntax
:CURSor[:TY]:MARKer:M<x>:V:STA
Te {<Boolean>}
:CURSor[:TY]:MARKer:M<x>:V:STATe?
<x> = 1 to 4
Example
:CURSOR:TY:MARKER:M1:V:STATE ON
:CURSOR:TY:MARKER:M1:V:STATE?
-> :CURSOR:TY:MARKER:M1:V:STATE 1
:CURSor[:TY]:MARKer:M<x>:V:VALue?
Function Queries the vertical value of a marker cursor.
Syntax
:CURSor[:TY]:MARKer:M<x>:V:VALue?
<x> = 1 to 4
Example
:CURSOR:TY:MARKER:M1:V:VALUE?
-> :CURSOR:TY:MARKER:M1:V:VALUE 1.500
0E−03
Description When linear scaling is on, the DLM2000 returns
the scaled value.
:CURSor[:TY]:MARKer:FORM
Function Sets or queries the marker cursor form.
Syntax
:CURSor[:TY]:MARKer:FORM {LINE|MARK}
:CURSor[:TY]:MARKer:FORM?
Example
:CURSOR:TY:MARKER:FORM LINE
:CURSOR:TY:MARKER:FORM?
-> :CURSOR:TY:MARKER:FORM LINE
:CURSor[:TY]:TYPE
Function Sets or queries the cursor type.
Syntax
:CURSor[:TY]:TYPE {OFF|HORizontal|
HAVertical|MARKer|VERTical|DEGRee}
:CURSor[:TY]:TYPE?
Example
:CURSOR:TY:TYPE HORizontal
:CURSOR:TY:TYPE?
-> :CURSOR:TY:TYPE HORizontal
:CURSor[:TY]:VERTical?
Function Queries all ΔTcursorsettings.
Syntax
:CURSor[:TY]:VERTical?
:CURSor[:TY]:VERTical:ALL
Function Collectively turns on or off the measured values of
theΔTcursorontheT-Ydisplay.
Syntax
:CURSor:TY:VERTical:ALL {<Boolean>}
Example
:CURSOR:TY:VERTICAL:ALL ON
:CURSor[:TY]:VERTical:DT?
Function QueriesalltimeaxissettingsfortheΔTcursors.
Syntax
:CURSor[:TY]:VERTical:DT?
:CURSor[:TY]:VERTical:DT:STATe
Function Sets or queries the on/off status of the time value
measuredbetweentheΔTcursors.
Syntax
:CURSor[:TY]:VERTical:DT:STATe {<Bool
ean>}
:CURSor[:TY]:VERTical:DT:STATe?
Example
:CURSOR:TY:VERTICAL:DT:STATE ON
:CURSOR:TY:VERTICAL:DT:STATE?
-> :CURSOR:TY:VERTICAL:DT:STATE 1
:CURSor[:TY]:VERTical:DT:VALue?
Function QueriesthetimevaluebetweentheΔTcursors.
Syntax
:CURSor[:TY]:VERTical:DT:VALue?
Example
:CURSOR:TY:VERTICAL:DT:VALUE?
-> :CURSOR:TY:VERTICAL:DT:VALUE 2.50E
−06
:CURSor[:TY]:VERTical:DV?
Function QueriesallverticalaxissettingsfortheΔTcursors.
Syntax
:CURSor[:TY]:VERTical:DV?
:CURSor[:TY]:VERTical:DV:STATe
Function Sets or queries the on/off status of the vertical
valuemeasuredbetweentheΔTcursors.
Syntax
:CURSor[:TY]:VERTical:DV:STATe {<Bool
ean>}
:CURSor[:TY]:VERTical:DV:STATe?
Example
:CURSOR:TY:VERTICAL:DV:STATE ON
:CURSOR:TY:VERTICAL:DV:STATE?
-> :CURSOR:TY:VERTICAL:DV:STATE 1
