YOKOGAWA DLM4038 User Manual

5-53
IM DLM4038-17EN
Commands
1
2
3
4
5
6
App
Index
Command Function Page
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:ENHanced:D16Bit:DAT
A:DECimal<x>
Sets or queries the slow channel enhanced type 16-bit data and 4-bit ID data
for SENT signal triggering in decimal notation.
5-288
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:ENHanced:D16Bit:DAT
A:HEXa
Sets the slow channel enhanced type 16-bit data and 4-bit ID data for SENT
signal triggering in hexadecimal notation.
5-288
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:ENHanced:D16Bit:DAT
A:MODE
Sets or queries the data enable/disable condition of the slow channel
enhanced type 16-bit data and 4-bit ID for SENT signal triggering.
5-288
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:ENHanced:D16Bit:DAT
A:PATTern
Sets the slow channel enhanced type 16-bit data and 4-bit ID data for SENT
signal triggering in binary notation.
5-289
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:ENHanced:D16Bit:DAT
A:PFORmat
Sets or queries the data input format, which is one of the slow channel
enhanced type 16-bit data and 4-bit ID data conditions, for SENT signal
triggering.
5-289
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:ENHanced:D16Bit:ID?
Queries all ID settings related to the slow channel enhanced type 16-bit data
and 4-bit ID for SENT signal triggering.
5-289
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:ENHanced:D16Bit:ID:
CONDition
Sets or queries the ID comparison condition of slow channel enhanced type
16-bit data and 4-bit ID for SENT signal triggering.
5-289
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:ENHanced:D16Bit:ID:
DECimal<x>
Sets the ID of the slow channel enhanced type 16-bit data and 4-bit ID for
SENT signal triggering in decimal notation.
5-289
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:ENHanced:D16Bit:ID:
MODE
Sets or queries the ID enable/disable condition of the slow channel enhanced
type 16-bit data and 4-bit ID for SENT signal triggering.
5-289
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:ENHanced:D16Bit:PFO
Rmat
Sets or queries the enhanced type 16-bit data and 4-bit ID input format of the
SENT signal trigger slow channel.
5-290
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:SHORt?
Queries all slow channel short type settings for SENT signal triggering. 5-290
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:SHORt:DATA?
Queries all slow channel short type data settings for SENT signal triggering. 5-290
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:SHORt:DATA:CONDiti
on
Sets or queries the short type data comparison condition of the SENT signal
trigger slow channel.
5-290
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:SHORt:DATA:DECimal
<x>
Sets or queries the SENT signal trigger slow channel short type data in
decimal notation.
5-290
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:SHORt:DATA:HEXa
Sets the SENT signal trigger slow channel short type data in hexadecimal
notation.
5-290
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:SHORt:DATA:MODE
Sets or queries the short type data enable/disable condition of the SENT
signal trigger slow channel.
5-290
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:SHORt:DATA:PATTern
Sets the SENT signal trigger slow channel short type data in binary notation. 5-290
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:SHORt:DATA:PFORmat
Sets or queries the data input format, which is one of the slow channel short
type data conditions, for SENT signal triggering.
5-291
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:SHORt:ID?
Queries all slow channel short type ID settings for SENT signal triggering. 5-291
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:SHORt:ID:CONDition
Sets or queries the short type ID comparison condition of the SENT signal
trigger slow channel.
5-291
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:SHORt:ID:DECimal<x>
Sets the SENT signal trigger slow channel short type ID in decimal notation. 5-291
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:SHORt:ID:MODE
Sets or queries the short type ID enable/disable condition of the SENT signal
trigger slow channel.
5-291
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SDATa:SHORt:PFORmat
Sets or queries the short type input format of the SENT signal trigger slow
channel.
5-291
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:SOURce
Sets or queries the SENT signal trigger source. 5-291
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:STYPe
Sets or queries the SENT signal trigger slow channel format. 5-291
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:USETup?
Queries all settings related to fast channel user-defined data of SENT signal
triggering.
5-292
5.1 List of Commands
