YOKOGAWA DLM4038 User Manual

5-54
IM DLM4038-17EN
Command Function Page
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:USETup:DATA<x>?
Queries all settings related to the specified user-defined data of the SENT
signal trigger fast channel.
5-292
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:USETup:DATA<x>:MODE
Sets or queries the enable/disable condition of the specified user-defined
data of the SENT signal trigger fast channel.
5-292
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:USETup:DATA<x>:ORDer
Sets or queries the byte order of the specified user-defined data of the SENT
signal trigger fast channel.
5-292
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:USETup:DATA<x>:SIZE
Sets or queries the data size of the specified user-defined data of the SENT
signal trigger fast channel.
5-292
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:USETup:MULTiplexing
Sets or queries the enable/disable condition of the multiplexing for the user-
defined data of the SENT signal trigger.
5-292
:TRIGger{[:ATRigger]|:BTRigger}
:SENT:VERSion
Sets or queries the SENT signal trigger specification version. 5-292
:TRIGger{[:ATRigger]|:BTRigger}
:SIMPle?
Queries all edge trigger settings. 5-293
:TRIGger{[:ATRigger]|:BTRigger}
:SIMPle:COUPling
Sets or queries the edge trigger source trigger coupling. 5-293
:TRIGger{[:ATRigger]|:BTRigg
er}:SIMPle:HFRejection (High
Frequency REJECTION)
Sets or queries the on/off status of the trigger source low-pass filter (HF
rejection) for edge triggering.
5-293
:TRIGger{[:ATRigger]|:BTRigger}
:SIMPle:HYSTeresis
Sets or queries the noise rejection setting for the edge trigger source trigger
level.
5-293
:TRIGger{[:ATRigger]|:BTRigger}
:SIMPle:LEVel
Sets or queries the edge trigger source trigger level. 5-293
:TRIGger{[:ATRigger]|:BTRigger}
:SIMPle:PROBe
Sets or queries the external trigger source probe setting for edge triggering. 5-293
:TRIGger{[:ATRigger]|:BTRigger}
:SIMPle:SLOPe
Sets or queries the trigger source slope setting (polarity setting when the
window is set to ON) for edge triggering.
5-294
:TRIGger{[:ATRigger]|:BTRigger}
:SIMPle:SOURce
Sets or queries the edge trigger source. 5-294
:TRIGger{[:ATRigger]|:BTRigger}
:SIMPle:WIDTh
Sets or queries the edge trigger source window width. 5-294
:TRIGger{[:ATRigger]|:BTRigger}
:SIMPle:WINDow
Sets or queries the edge trigger source window. 5-294
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern?
Queries all user-defined bus signal trigger settings. 5-294
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:BITSize
Sets or queries the bit length setting for user-defined bus signal triggering. 5-294
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:BRATe
Sets or queries the bit rate setting for user-defined bus signal triggering. 5-294
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:CLOCk?
Queries all clock signal settings for user-defined bus signal triggering. 5-295
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:CLOCk:MODE
Sets or queries the clock signal enable or disable status for user-defined bus
signal triggering.
5-295
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:CLOCk:POLarity
Sets or queries the clock signal polarity for user-defined bus signal triggering. 5-295
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:CLOCk:SOURce
Sets or queries the clock signal for user-defined bus signal triggering. 5-295
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:CS?
Queries all chip select signal settings for user-defined bus signal triggering. 5-295
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:CS:ACTive
Sets or queries the chip select signal active state for user-defined bus signal
triggering.
5-295
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:CS:SOURce
Sets or queries the chip select signal for user-defined bus signal triggering. 5-295
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:DATA?
Queries all data signal settings for user-defined bus signal triggering. 5-295
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:DATA:ACTive
Sets or queries the data signal active state for user-defined bus signal
triggering.
5-296
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:DATA:SOURce
Sets or queries the data signal for user-defined bus signal triggering. 5-296
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:HEXa
Sets the data conditions of the user-defined bus trigger in hexadecimal
notation.
5-296
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:LATCh?
Queries all latch signal settings for user-defined bus signal triggering. 5-296
5.1 List of Commands
