YOKOGAWA DLM4038 User Manual

5-55
IM DLM4038-17EN
Commands
1
2
3
4
5
6
App
Index
Command Function Page
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:LATCh:POLarity
Sets or queries the latch signal polarity for user-defined bus signal triggering. 5-296
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:LATCh:SOURce
Sets or queries the latch signal for user-defined bus signal triggering. 5-296
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:PATTern
Sets or queries the data condition for user-defined bus signal triggering in
binary notation.
5-296
:TRIGger{[:ATRigger]|:BTRigger}
:SPATtern:PFORmat
Sets or queries the input format, which is one of the data conditions, for user-
defined bus signal triggering.
5-297
:TRIGger{[:ATRigger]|:BTRigger}
:SPI?
Queries all SPI bus signal trigger settings. 5-297
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:BITorder
Sets or queries the bit order of the SPI bus signal trigger data. 5-297
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:CLOCk?
Queries all clock signal settings for SPI bus signal triggering. 5-297
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:CLOCk:POLarity
Sets or queries the clock signal polarity for SPI bus signal triggering. 5-297
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:CLOCk:SOURce
Sets or queries the clock signal for SPI bus signal triggering. 5-297
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:CS?
Queries all chip select signal settings for SPI bus signal triggering. 5-297
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:CS:ACTive
Sets or queries the chip select signal active state for SPI bus signal
triggering.
5-297
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:CS:SOURce
Sets or queries the chip select signal for SPI bus signal triggering. 5-297
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:DATA<x>?
Queries all data signal settings for SPI bus signal triggering. 5-298
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:DATA<x>:BCOunt
Sets or queries the starting position of data comparison for SPI bus signal
triggering.
5-298
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:DATA<x>:CONDition
Sets or queries the data comparison condition (true or false) for SPI bus
signal triggering.
5-298
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:DATA<x>:DBYTe
Sets or queries the data size (in bytes) for SPI bus signal triggering. 5-298
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:DATA<x>:HEXa<y>
Sets a data value for SPI bus signal triggering in hexadecimal notation. 5-298
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:DATA<x>:MODE
Sets or queries the data enable/disable condition for SPI bus signal triggering
(on/off).
5-298
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:DATA<x>:PATTern<y>
Sets or queries the data value for SPI bus signal triggering in binary notation. 5-298
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:DATA<x>:PFORmat
Sets or queries the data input format, which is one of the data conditions, for
SPI bus signal triggering.
5-298
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:DATA<x>:SOURce
Sets or queries the data signal for SPI bus signal triggering. 5-299
:TRIGger{[:ATRigger]|:BTRigger}
:SPI:MODE
Sets or queries the wiring system (three-wire or four-wire) for SPI bus signal
triggering.
5-299
:TRIGger{[:ATRigger]|:BTRigger}
:TYPE
Sets or queries the trigger type. 5-299
:TRIGger{[:ATRigger]|:BTRigger}
:UART?
Queries all UART signal trigger settings. 5-299
:TRIGger{[:ATRigger]|:BTRigger}
:UART:BITorder
Sets or queries the UART signal trigger bit order. 5-299
:TRIGger{[:ATRigger]|:BTRigger}
:UART:BRATe
Sets or queries the UART signal trigger bit rate (data transfer rate). 5-299
:TRIGger{[:ATRigger]|:BTRigger}
:UART:DATA?
Queries all UART signal trigger data settings. 5-299
:TRIGger{[:ATRigger]|:BTRigger}
:UART:DATA:ASCii
Sets the UART bus signal trigger data in ASCII format. 5-299
:TRIGger{[:ATRigger]|:BTRigger}
:UART:DATA:CONDition
Sets or queries the data comparison condition (true or false) for UART signal
triggering.
5-300
:TRIGger{[:ATRigger]|:BTRigger}
:UART:DATA:CSENsitive
Sets or queries whether to distinguish uppercase and lowercase letters in
ASCII data for the UART bus signal trigger.
5-300
:TRIGger{[:ATRigger]|:BTRigger}
:UART:DATA:DBYTe
Sets or queries the number of data bytes for UART signal triggering. 5-300
:TRIGger{[:ATRigger]|:BTRigger}
:UART:DATA:HEXa<x>
Sets the data for UART signal triggering in hexadecimal notation. 5-300
5.1 List of Commands
