YOKOGAWA DLM4038 User Manual

5-56
IM DLM4038-17EN
Command Function Page
:TRIGger{[:ATRigger]|:BTRigger}
:UART:DATA:PATTern<x>
Sets or queries the data value for UART signal triggering in binary notation. 5-300
:TRIGger{[:ATRigger]|:BTRigger}
:UART:DATA:PFORmat
Sets or queries the data input format, which is one of the ID and data
conditions, for UART signal triggering.
5-300
:TRIGger{[:ATRigger]|:BTRigger}
:UART:ERRor?
Queries all UART signal trigger error settings. 5-300
:TRIGger{[:ATRigger]|:BTRigger}
:UART:ERRor:FRAMing
Sets or queries the UART signal trigger framing error setting. 5-301
:TRIGger{[:ATRigger]|:BTRigger}
:UART:ERRor:PARity
Sets or queries the UART signal trigger parity error setting. 5-301
:TRIGger{[:ATRigger]|:BTRigger}
:UART:ERRor:PMODE
Sets or queries the UART signal trigger parity mode setting. 5-301
:TRIGger{[:ATRigger]|:BTRigger}
:UART:FORMat
Sets or queries the UART signal trigger format. 5-301
:TRIGger{[:ATRigger]|:BTRigger}
:UART:MODE
Sets or queries the UART signal trigger type. 5-301
:TRIGger{[:ATRigger]|:BTRigger}
:UART:POLarity
Sets or queries the UART signal trigger polarity. 5-301
:TRIGger{[:ATRigger]|:BTRigger}
:UART:SOURce
Sets or queries the source signal for UART signal triggering. 5-301
:TRIGger{[:ATRigger]|:BTRigger}
:UART:SPOint
Sets or queries the UART signal trigger sample point. 5-301
:TRIGger[:ATRigger]:OR?
Sets or queries the edge of a channel for edge OR triggering. 5-301
:TRIGger[:ATRigger]:OR:ALL
Sets or queries whether to make all channels edge OR trigger sources at
once.
5-302
:TRIGger[:ATRigger]:OR:CHANnel
<x>
Sets or queries the slope of each channel of the edge OR trigger. 5-302
:TRIGger[:ATRigger]:PSI5?
Queries all PSI5 signal trigger settings. 5-302
:TRIGger[:ATRigger]:PSI5:DATA?
Queries all PSI5 signal trigger data settings. 5-302
:TRIGger[:ATRigger]:PSI5:DATA:C
ONDition
Sets or queries the data condition for PSI5 signal triggering. 5-302
:TRIGger[:ATRigger]:PSI5:DATA:D
ECimal
Sets or queries the data for PSI5 signal triggering in decimal notation. 5-302
:TRIGger[:ATRigger]:PSI5:DATA:H
EXa
Sets the data for PSI5 signal triggering in hexadecimal notation. 5-302
:TRIGger[:ATRigger]:PSI5:DATA:P
ATTern
Sets or queries the data for PSI5 signal triggering in binary notation. 5-302
:TRIGger[:ATRigger]:PSI5:DATA:P
FORmat
Sets or queries the data input format for PSI5 signal triggering. 5-302
:TRIGger[:ATRigger]:PSI5:MODE
Sets or queries the PSI5 signal trigger mode. 5-303
:TRIGger[:ATRigger]:PSI5:SETup?
Queries all bus setup settings for PSI5 signal triggering. 5-303
:TRIGger[:ATRigger]:PSI5:SETup:
DATA?
Queries all PSI5 signal trigger data signal settings. 5-303
:TRIGger[:ATRigger]:PSI5:SETup:
DATA:BRATe
Sets or queries the PSI5 signal trigger bit rate (data transfer rate). 5-303
:TRIGger[:ATRigger]:PSI5:SETup:
DATA:DBITs
Sets or queries the data length for PSI5 signal triggering. 5-303
:TRIGger[:ATRigger]:PSI5:SETup:
DATA:EDETection
Sets or queries the error detection method for PSI5 signal triggering. 5-303
:TRIGger[:ATRigger]:PSI5:SETup:
DATA:SOURce
Sets or queries the data source for PSI5 signal triggering. 5-303
:TRIGger[:ATRigger]:PSI5:SETup:
SYNC
Sets or queries the sync signal for PSI5 signal triggering. 5-303
:TRIGger[:ATRigger]:PULSe?
Queries all pulse width trigger settings. 5-304
:TRIGger[:ATRigger]:PULSe:POLar
ity
Sets or queries the pulse width trigger source polarity. 5-304
:TRIGger[:ATRigger]:PULSe:SOUR
ce
Sets or queries the pulse width trigger source. 5-304
:TRIGger[:ATRigger]:TV?
Queries all TV trigger settings. 5-304
:TRIGger[:ATRigger]:TV:FIELd
Sets or queries the field where TV triggering will be used. 5-304
:TRIGger[:ATRigger]:TV:FRAMe
Sets or queries the frame skip feature for TV triggering. 5-304
:TRIGger[:ATRigger]:TV:{HDTV|NT
SC|PAL|SDTV|USERdefine}?
Queries all TV trigger mode settings. 5-304
5.1 List of Commands
