YOKOGAWA DLM4038 User Manual

5-57
IM DLM4038-17EN
Commands
1
2
3
4
5
6
App
Index
Command Function Page
:TRIGger[:ATRigger]:TV:{HDTV|NT
SC|PAL|SDTV|USERdefine}:LINE
Sets or queries the line where TV triggering will be used. 5-304
:TRIGger[:ATRigger]:TV:{HDTV|NT
SC|PAL|SDTV|USERdefine}:POLari
ty
Sets or queries the TV trigger input polarity. 5-304
:TRIGger[:ATRigger]:TV:LEVel
Sets or queries the TV trigger level. 5-304
:TRIGger[:ATRigger]:TV:LFORmat
Sets or queries the format for specifying the line where TV triggering will be
used.
5-304
:TRIGger[:ATRigger]:TV:SOURce
Sets or queries the TV trigger source. 5-305
:TRIGger[:ATRigger]:TV:TYPE
Sets or queries the TV trigger input type. 5-305
:TRIGger[:ATRigger]:TV:USERdefi
ne?
Queries all user-defined TV trigger settings. 5-305
:TRIGger[:ATRigger]:TV:USERdefi
ne:DEFinition
Sets or queries the user-defined TV trigger definition setting. 5-305
:TRIGger[:ATRigger]:TV:USERdefi
ne:HFRejection (High Frequency
REJECTION)
Sets or queries the low-pass filter (HF rejection) setting for user-defined TV
triggering.
5-305
:TRIGger[:ATRigger]:TV:USERdefi
ne:HSYNc (Hsync Freq)
Sets or queries the horizontal sync frequency for user-defined TV triggering. 5-305
:TRIGger[:ATRigger]:TV:USERdefi
ne:LINE
Sets or queries the user-defined TV trigger line number. 5-305
:TRIGger[:ATRigger]:TV:USERdefi
ne:POLarity
Sets or queries the user-defined TV trigger input polarity. 5-305
:TRIGger[:ATRigger]:TV:USERdefi
ne:SGUard
Sets or queries the user-defined TV trigger sync guard setting. 5-306
:TRIGger[:ATRigger]:WIDTh?
Queries all state width trigger settings. 5-306
:TRIGger[:ATRigger]:WIDTh:CHANn
el<x>
Sets or queries the trigger condition of a channel for state width triggering. 5-306
:TRIGger[:ATRigger]:WIDTh:CLO
Ck?
Queries all clock signal settings for state width triggering. 5-306
:TRIGger[:ATRigger]:WIDTh:CLOCk
:POLarity
Sets or queries the clock signal polarity for state width triggering. 5-306
:TRIGger[:ATRigger]:WIDTh:CLOCk
:SOURce
Sets or queries the clock signal for state width triggering. 5-306
:TRIGger[:ATRigger]:WIDTh:CONDi
tion
Sets or queries the trigger condition for state width triggering. 5-306
:TRIGger[:ATRigger]:WIDTh:LOGic
Sets or queries the combination condition for state width triggering. 5-306
:TRIGger[:ATRigger]:WIDTh:{PODA
|PODB|PODL}?
Queries all the settings for the state width trigger logic input. 5-306
:TRIGger[:ATRigger]:WIDTh:{PODA
|PODB|PODL}:HEXa
Sets the logic input state of the state width trigger in hexadecimal notation. 5-306
:TRIGger[:ATRigger]:WIDTh:{PODA
|PODB|PODL}:PATTern
Sets or queries the logic input state of the state width trigger with a pattern. 5-307
:TRIGger[:ATRigger]:WIDTh:TIME
<x>
Sets or queries the pulse width setting for state width triggering. 5-307
:TRIGger[:ATRigger]:WIDTh:TYPE
Sets or queries the time width mode for state width triggering. 5-307
:TRIGger:COMBination
Sets or queries the trigger combination. 5-307
:TRIGger:DELay?
Queries all delay settings. 5-307
:TRIGger:DELay:TIME
Sets or queries the delay (the time between the trigger point and the trigger
position).
5-307
:TRIGger:FORCe
Forces the DLM4000 to trigger. 5-307
:TRIGger:HOLDoff?
Queries all hold-off settings. 5-307
:TRIGger:HOLDoff:TIME
Sets or queries the hold-off time. 5-307
:TRIGger:MODE
Sets or queries the trigger mode. 5-307
:TRIGger:POSition
Sets or queries the trigger position. 5-307
:TRIGger:SCOunt
Sets or queries the number of times the trigger condition must be met when
the trigger mode is set to Single (N).
5-308
:TRIGger:SOURce?
Queries all trigger source settings for enhanced triggering. 5-308
:TRIGger:SOURce:CHANnel<x>?
Queries all of the settings of the specified trigger source for enhanced
triggering.
5-308
:TRIGger:SOURce:CHANnel<x>:COUP
ling
Sets or queries the specified trigger source trigger coupling for enhanced
triggering.
5-308
5.1 List of Commands
