5-58
IM DLM4038-17EN
Command Function Page
:TRIGger:SOURce:CHANnel<x>:
HFRejection (HIgh Frequency
REJECTION)
Sets or queries the low-pass filter setting of the specified trigger source for
enhanced triggering.
5-308
:TRIGger:SOURce:CHANnel<x>:HYST
eresis
Sets or queries the noise rejection setting of the specified trigger source for
enhanced triggering.
5-308
:TRIGger:SOURce:CHANnel<x>:LEV
el
Sets or queries the trigger level of the specified trigger source for enhanced
triggering.
5-308
:TRIGger:SOURce:CHANnel<x>:WID
Th
Sets or queries the window width of the specified trigger source for enhanced
triggering.
5-308
:TRIGger:SOURce:CHANnel<x>:WIND
ow
Enhanced Sets or queries the window on/off status of the specified trigger
source for enhanced triggering.
5-309
WAVeform Group
:WAVeform?
Queries all information about waveform data. 5-310
:WAVeform:ALL?
Queries all settings related to the
:WAVeform:ALL:SEND?
query. 5-310
:WAVeform:ALL:SEND?
Queries the waveform data specified by the
:WAVeform:ALL:TRACe
command.
5-310
:WAVeform:ALL:TRACe
Sets or queries the waveform that is the target of the
:WAVeform:ALL:SEND?
query.
5-311
:WAVeform:BITS?
Queries the bit length of the waveform data specified by the
:WAVeform:TRACe
command.
5-311
:WAVeform:BYTeorder
Sets or queries the transmission byte order for waveform data in word format
that is 2 bytes or longer in length.
5-311
:WAVeform:END
Sets or queries which point will be used as the last data value for the
waveform specified by
:WAVeform:TRACe
.
5-311
:WAVeform:FORMat
Sets or queries the format of the waveform data to be sent. 5-311
:WAVeform:LENGth?
Queries the total number of data points of the waveform data specified by
the
:WAVeform:TRACe
command.
5-311
:WAVeform:OFFSet?
Queries the offset value used to convert the waveform data specified by the
:WAVeform:TRACe
command to physical values.
5-311
:WAVeform:POSition?
Queries the vertical position that is used to convert waveform data to voltage
when
:WAVeform:FORMat
is set to RBYTe.
5-311
:WAVeform:RANGe?
Queries the range used to convert the waveform data specified by the
:WAVeform:TRACe
command to physical values.
5-311
:WAVeform:RECord
Sets or queries the record number that WAVeform commands will be applied
to.
5-311
:WAVeform:RECord? MINimum
Queries the minimum record number of the source channel. 5-312
:WAVeform:SEND?
Queries the waveform data specified by the
:WAVeform:TRACe
command. 5-312
:WAVeform:SIGN?
Queries whether or not signs are included in the binary data of the source
waveform specified by
:WAVeform:TRACe
when the data is queried.
5-312
:WAVeform:SRATe? (Sample RATE)
Queries the sample rate of the record specified by the
:WAVeform:RECord
command.
5-312
:WAVeform:STARt
Sets or queries which point will be used as the first data value for the
waveform specified by
:WAVeform:TRACe
.
5-312
:WAVeform:TRACe
Sets or queries the waveform that
WAVeform
commands will be applied to. 5-312
:WAVeform:TRIGger?
Queries the trigger position of the record specified by the
:WAVeform:RECord command
.
5-312
:WAVeform:TYPE?
Queries the acquisition mode of the waveform specified by the
:WAVeform:TRACe command
.
5-312
WPARameter Group
:WPARameter<x>?
Queries all of the settings for the waveform parameter measurement feature. 5-313
:WPARameter<x>:DISPlay
Sets or queries the on/off status of waveform parameter measurement
display.
5-313
:WPARameter<x>:HISTogram?
Queries all histogram display settings for waveform parameter measurement. 5-313
:WPARameter<x>:HISTogram:MEASu
re?
Queries all automatic measurement settings of the histogram display for
waveform parameter measurement.
5-313
:WPARameter<x>:HISTogram:MEASur
e:MODE
Sets or queries the automatic measurement mode of the histogram display
for waveform parameter measurement.
5-313
:WPARameter<x>:HISTogram:MEASur
e:PARameter?
Queries all automatic measurement settings of the histogram parameter for
waveform parameter measurement.
5-313
5.1 List of Commands
