YOKOGAWA DLM4038 User Manual

5-59
IM DLM4038-17EN
Commands
1
2
3
4
5
6
App
Index
5.1 List of Commands
Command Function Page
:WPARameter<x>:HISTogram:MEASur
e:PARameter:ALL
Collectively turns on or off all histogram parameters for waveform parameter
measurement.
5-313
:WPARameter<x>:HISTogram:MEASur
e:PARameter:<Parameter>?
Queries all of the settings of a histogram parameter for waveform parameter
measurement.
5-313
:WPARameter<x>:HISTogram:MEASur
e:PARameter:<Parameter>:STATe
Sets or queries the on/off status of a histogram parameter for waveform
parameter measurement.
5-313
:WPARameter<x>:HISTogram:MEASur
e:PARameter:<Parameter>:VALue?
Queries the measured value of a histogram parameter for waveform
parameter measurement.
5-314
:WPARameter<x>:HISTogram:MEASur
e:PARameter:POSition<y>
Sets or queries the position of a histogram parameter for waveform
parameter measurement.
5-314
:WPARameter<x>:ITEM
Sets or queries a waveform parameter for waveform parameter
measurement.
5-314
:WPARameter<x>:MODE
Sets or queries the waveform parameter measurement mode. 5-314
:WPARameter<x>:TRENd?
Queries all trend display settings for waveform parameter measurement. 5-314
:WPARameter<x>:TRENd:ASCale
Executes auto scaling of the trend display for waveform parameter
measurement.
5-314
:WPARameter<x>:TRENd:CURSor?
Queries all cursor measurement settings of the trend display for waveform
parameter measurement.
5-315
:WPARameter<x>:TRENd:CURSor:C
<y>?
Queries the measured value of a cursor in the trend display for waveform
parameter measurement.
5-315
:WPARameter<x>:TRENd:CURSor:DC?
Queries the measured value between cursors in the trend display for
waveform parameter measurement.
5-315
:WPARameter<x>:TRENd:CURSor:MO
DE
Sets or queries the automatic measurement mode of the trend display for
waveform parameter measurement.
5-315
:WPARameter<x>:TRENd:CURSor:POS
ition<y>
Sets or queries the position of a cursor in the trend display for waveform
parameter measurement.
5-315
:WPARameter<x>:TRENd:HRANge
Sets or queries the trend display source window for waveform parameter
measurement.
5-315
:WPARameter<x>:TRENd:HSPan
Sets or queries the horizontal span of the trend display for waveform
parameter measurement.
5-315
:WPARameter<x>:TRENd:VERTical
Sets or queries the vertical range of the trend display for waveform
parameter measurement.
5-315
:WPARameter<x>:VTDisplay
Sets or queries the on/off status of VT waveform display. 5-315
:WPARameter<x>:WAIT?
Waits for the completion of automated measurement with a set timeout. 5-316
XY Group
:XY<x>?
Queries all XY display settings. 5-317
:XY<x>:DISPlay
Sets or queries the on/off status of the XY display. 5-317
:XY<x>:MEASure?
Queries all automated measurement settings for the XY display. 5-317
:XY<x>:MEASure:CURSor?
Queries all cursor measurement settings for the XY display. 5-317
:XY<x>:MEASure:CURSor:DX?
Queries all settings for the voltage difference between theXY display’s
horizontal cursors.
5-317
:XY<x>:MEASure:CURSor:DX:STATe
Sets or queries the on/off status of the voltage difference between theXY
display’s horizontal cursors.
5-317
:XY<x>:MEASure:CURSor:DX:VALue?
Queries the voltage difference between theXY display’s horizontal cursors. 5-317
:XY<x>:MEASure:CURSor:DY?
Queries all settings for the voltage difference between the XY display’s
vertical cursors.
5-317
:XY<x>:MEASure:CURSor:DY:STATe
Sets or queries the on/off status of the voltage difference between the XY
display’s vertical cursors.
5-317
:XY<x>:MEASure:CURSor:DY:VALue?
Queries the voltage difference between theXY display’s vertical cursors. 5-317
:XY<x>:MEASure:CURSor:X<y>?
Queries all horizontal cursor settings for the XY display. 5-317
:XY<x>:MEASure:CURSor:X<y>:POSi
tion
Sets or queries a horizontal cursor position in the XY display. 5-317
:XY<x>:MEASure:CURSor:X<y>:STA
Te
Sets or queries the on/off status of the voltage of an XY display horizontal
cursor.
5-318
:XY<x>:MEASure:CURSor:X<y>:VAL
ue?
Queries the voltage of a horizontal cursor in the XY display. 5-318
:XY<x>:MEASure:CURSor:Y<y>?
Queries all vertical cursor settings for the XY display. 5-318
:XY<x>:MEASure:CURSor:Y<y>:POSi
tion
Sets or queries a vertical cursor position in the XY display. 5-318
:XY<x>:MEASure:CURSor:Y<y>:STA
Te
Sets or queries the on/off status of the voltage of an XY display vertical
cursor.
5-318
