YOKOGAWA DLM4038 User Manual

5-60
IM DLM4038-17EN
Command Function Page
:XY<x>:MEASure:CURSor:Y<y>:VAL
ue?
Queries the voltage of a vertical cursor in the XY display. 5-318
:XY<x>:MEASure:INTeg?
Queries all integration settings for the XY display. 5-318
:XY<x>:MEASure:INTeg:LOOP
Sets or queries the integration method for the XY display 5-318
:XY<x>:MEASure:INTeg:POLarity
Sets or queries the integration polarity for the XY display. 5-318
:XY<x>:MEASure:INTeg:VALue?
Queries the integrated value for the XY display. 5-318
:XY<x>:MEASure:MODE
Sets or queries the automated measurement mode for the XY display. 5-318
:XY<x>:SPLit
Sets or queries whether or not the XY display are split. 5-319
:XY<x>:TRANge (Time Range)
Sets or queries the range of T-Y waveform to display in the XY display. 5-319
:XY<x>:VTDisplay
Sets or queries the on/off status of the VT waveform display for the XY
display.
5-319
:XY<x>:XTRace
Sets or queries the channel that is assigned to the X-axis in the XY display. 5-319
:XY<x>:YTRace
Sets or queries the channel that is assigned to the Y-axis in the XY display. 5-319
ZOOM Group
:ZOOM<x>?
Queries all waveform zoom settings. 5-320
:ZOOM<x>:ALLocation?
Queries all zoom source waveform settings. 5-320
:ZOOM<x>:ALLocation:ALL
Sets the zoom source to all waveforms. 5-320
:ZOOM<x>:ALLocation:{CHANnel<y>
|MATH<y>}
Sets or queries the zoom source waveform. 5-320
:ZOOM<x>:DISPlay
Sets or queries the on/off status of a zoom waveform display. 5-320
:ZOOM<x>:FORMat
Sets or queries the format of a zoom waveform display. 5-320
:ZOOM<x>:MAG
Sets or queries the magnification of a zoom waveform display. 5-320
:ZOOM<x>:MAGFine
Sets or queries the magnification (FINE) of a zoom waveform display. 5-320
:ZOOM<x>:MAIN
Sets or queries the display ratio of a zoom waveform display. 5-320
:ZOOM<y>:POSition
Sets or queries the position of a zoom box. 5-320
:ZOOM<x>:VERTical?
Queries all vertical zoom settings. 5-320
:ZOOM<x>:VERTical:{CHANnel<y>|M
ATH<y>}?
Queries all of the settings of a trace for vertical zooming. 5-321
:ZOOM<x>:VERTical:{CHANnel<y>|M
ATH<y>}:MAG
Sets or queries the vertical zoom factor. 5-321
:ZOOM<x>:VERTical:{CHANnel<y>|M
ATH<y>}:POSition
Sets or queries the vertical zoom position. 5-321
:ZOOM<x>:VERTical:TRACe
Sets or queries the trace that is displayed in the vertical zoom window. 5-321
Common Command Group
*CAL? (CALibrate)
Executed calibration and queries the result. 5-322
*CLS (CLear Status)
Clears the standard event register, extended event register, and error queue. 5-322
*ESE (standard Event Status
Enable register)
Sets or queries the standard event enable register. 5-322
*ESR? (standard Event Status
Register)
Queries and clears the standard event register. 5-322
*IDN? (IDeNtify)
Queries the DLM4000 model. 5-322
*OPC (OPeration Complete)
Sets bit 0 (the OPC bit) of the standard event register to 1 upon the
completion of the specified overlap command.
5-322
*OPC? (OPeration Complete)
If you send *OPC?, the DLM4000 returns ASCII code 1 when the specified
overlap command is completed.
5-323
*OPT? (OPTion)
Queries the installed options. 5-323
*RST (ReSeT)
Resets the settings. 5-323
*SRE (Service Request Enable
register)
Sets or queries the service request enable register value. 5-323
*STB? (STatus Byte)
Queries the status byte register value. 5-323
*TST?
Performs a self-test and queries the result. The self-test consists of tests of
each kind of internal memory.
5-323
*WAI (WAIt)
Holds the subsequent command until the completion of the specified overlap
operation.
5-324
5.1 List of Commands
