Table C3.3 Input Type Selection (2/2) (SW1-1 = ON)
Input Type Instrument Range
Input Type
Selector Switch
*2
Software
Setting
Input Range
Default Allowable
Range
SW5 SW1-4 SW1-3
IN
RL RH DEC.P RL RH
Software setting
0 OFF X
Thermocouple
K
-328.0 to 2498.0F 1
OFF
OFF 1 ($01) -3280 24980 1 -4540 24980
ON 33 ($21) -328 2498 0 -454 2498
-328.0 to 1832.0F 2
OFF 2 ($02) -3280 18320 1 -4540 24980
ON 34 ($22) -328 1832 0 -454 2498
-328.0 to 932.0F 3
OFF 3 ($03) -3280 9320 1 -3280 9320
ON 35 ($23) -328 932 0 -328 932
J
-328.0 to 2192.0F 4
OFF 4 ($04) -3280 21920 1 -3280 21920
ON 36 ($24) -328 2192 0 -328 2192
-328.0 to 932.0F 5
OFF 5 ($05) -3280 9320 1 -3280 9320
ON 37 ($25) -328 932 0 -328 932
T
-454.0 to 752.0F 6
OFF 6 ($06) -4540 7520 1 -4540 7520
ON 38 ($26) -454 752 0 -454 752
B
32 to 2912 F 7
OFF 7 ($07) 32 2912 0 32 3272
ON 39 ($27) 32 2912 0 32 3272
S
32 to 2912 F 8
OFF 8 ($08) 32 2912 0 32 3092
ON 40 ($28) 32 2912 0 32 3092
R
32 to 2912 F 9
OFF 9 ($09) 32 2912 0 32 3092
ON 41 ($29) 32 2912 0 32 3092
N
-328.0 to 2372.0F A
OFF 10 ($0A) -3280 23720 1 -3280 23720
ON 42 ($2A) -328 2372 0 -328 2372
E
-454.0 to 1832.0F B
OFF 11 ($0B) -4540 18320 1 -4540 18320
ON 43 ($2B) -454 1832 0 -454 1832
L
-328.0 to 1652.0F C
OFF 12 ($0C) -3280 16520 1 -3280 16520
ON 44 ($2C) -328 1652 0 -328 1652
U
-328.0 to 752.0F D
OFF 13 ($0D) -3280 7520 1 -3280 7520
ON 45 ($2D) -328 752 0 -328 752
W
32 to 2912 F E
OFF 14 ($0E) 32 2912 0 32 4172
ON 46 ($2E) 32 2912 0 32 4172
Platinel 2
32.0 to 2534.0F F
OFF 15 ($0F) 320 25340 1 320 25340
ON 47 ($2F) 32 2534 0 32 2534
RTD
JPt100
-328.0 to 932.0F 0
ON
OFF 16 ($10) -3280 9320 1 -3280 9320
ON 48 ($30) -328 932 0 -328 932
-328.0 to 392.0F 1
OFF 17 ($11) -3280 3920 1 -3280 3920
ON 49 ($31) -328 392 0 -328 392
32.0 to 572.0F 2
OFF 18 ($12) 320 5720 1 320 5720
ON 50 ($32) 32 572 0 32 572
32.0 to 302.0F 3
OFF 19 ($13) 320 3020 1 320 3020
ON 51 ($33) 32 302 0 32 302
Pt100
-328.0 to 1562.0F 4
OFF 20 ($14) -3280 15620 1 -3280 15620
ON 52 ($34) -328 1562 0 -328 1562
-328.0 to 932.0F 5
OFF 21 ($15) -3280 9320 1 -3280 9320
ON 53 ($35) -328 932 0 -328 932
-328.0 to 392.0F 6
OFF 22 ($16) -3280 3920 1 -3280 3920
ON 54 ($36) -328 392 0 -328 392
32.0 to 572.0F 7
OFF 23 ($17) 320 5720 1 320 5720
ON 55 ($37) 32 572 0 32 572
32.0 to 302.0F 8
OFF 24 ($18) 320 3020 1 320 3020
ON 56 ($38) 32 302 0 32 302
DC voltage
0-10mV 0.00 to 10.00 mV 9
ON
X
25 ($19) 0 1000 2 0 1000
0-100mV 0.0 to 100.0 mV A 26 ($1A) 0 1000 1 0 1000
0-1V 0.000 to 1.000 V B 27 ($1B) 0 1000 3 0 1000
0-5V 0.000 to 5.000 V D 29 ($1D) 0 5000 3 0 5000
1-5V 1.000 to 5.000 V E 30 ($1E) 1000 5000 3 1000 5000
0-10V 0.00 to10.00 V F 31 ($1F) 0 1000 2 0 1000
*1: For thermocouples K, B, S, R, and W, the upper and lower input range limits may exceed their default values.
*2: Data stored in the internal memory is initialized to the hardware switch values when power is turned on. An ‘X’ symbol in the SW1-3
column indicates that the switch setting is ignored.
*3: “Software Setting” refers to values stored in data register IN. Any value not listed here is ignored.
*4: This is the factory setting. When ‘set by software’ is selected, the initial value of data register IN is ‘I: Thermocouple K’.
