E1-3
IM 34M06H62-02E 2nd Edition : June 2008-00
Table E1.6 Process Data
Data Position Number
Symbol Description Attribute Stored
See
Also
Loop 1 Loop 2 Loop 3
Loop 4
101 301 501 701 PVIN Input process value RO —
C3.
102 302 502 702 PV Process value RO —
103 303 503 703 CSP Control set point RO — C4.
104 304 504 704 HOUT Control output RO —
C2.
C7.1
105 305 505 705 COUT Cooling control output RO —
106 306 506 706 PIDNO Current PID number RO — C6.9
107 307 507 707 CSPNO Current SP number RO — C4.1
108 308 508 708 RUN.STUS Operating status RO — C10.
109 309 509 709 ALM.STUS Alarm status RO — C8.
110 310 510 710 ERR.STUS Error status RO — C10.
111 311 511 711 AT.STUS Auto-tuning status RO — C5.2
112 312 512 712
Not used
113 313 513 713
114 314 514 714
115 315 515 715
116 316 516 716
117 317 517 717
118 318 518 718
119 319 519 719
120 320 520 720
Table E1.7 Operation Control Parameters
Data Position Number
Symbol Description Attribute Stored
See
Also
Loop 1 Loop 2 Loop 3
Loop 4
121 321 521 721 RUN/STP Run/stop selection RW — C7.1
122 322 522 722 A/M/C Auto/manual/cascade selection RW —
C7.2
C7.4
123 323 523 723 INSEL Input selection RW — C3.11
124 324 524 724 RMT/LOC Remote/local selection RW — C7.3
125 325 525 725 EXPV/PV External/normal input selection RW — C3.12
126 326 526 726 EXOUT/OUT External/normal output selection RW — C2.6
127 327 527 727 AT Start auto-tuning RW — C5.2
128 328 528 728 SPNO SP number selection RW — C4.1
129 329 529 729
Not used
130 330 530 730
131 331 531 731 EXPV External input RW — C3.12
132 332 532 732 EXRJC Reference junction temperature RW — C3.6
133 333 533 733 RSP Remote set point RW — C4.2
134 334 534 734 MOUT Manual output RW —
C7.2
C7.4
135 335 535 735 MOUTC Manual cooling output RW —
136 336 536 736 EXOUT External output RW — C2.6
137 337 537 737
Not used
138 338 538 738
139 339 539 739
140 340 540 740
To Next Page
