Table E1.8 I/O Parameters
Data Position Number
Symbol Description Attribute Stored
See
Also
Loop 1 Loop 2 Loop 3 Loop 4
141 341 541 741 OT Control type selection RW  C2.1
142 342 542 742 IN Input type selection RW  C3.1
143 343 543 743 RH Input range upper limit
RW 
C3.3
144 344 544 744 RL Input range lower limit
145 345 545 745 DEC.P Decimal point position RO 
146 346 546 746 SH Scaling upper limit RW 
147 347 547 747 SL Scaling lower limit RW 
148 348 548 748 SDP Scaling decimal point position RW 
149 349 549 749 RJC Reference junction compensation RW  C3.6
150 350 550 750 BSL Burnout selection RW  C3.5
151 351 551 751 PRH PV range upper limit RW 
C3.4 152 352 552 752 PRL PV range lower limit RW 
153 353 553 753 PDP PV range decimal point position RW 
154 354 554 754
Not used
155 355 555 755
156 356 556 756
157 357 557 757
158 358 558 758
159 359 559 759
160 360 560 760
