YOKOGAWA F3CU04-0S User Manual

E1-5
IM 34M06H62-02E 2nd Edition : June 2008-00
Table E1.9 Operation Parameters (1/3)
Data Position Number
Symbol Description Attribute Stored
See
Also
Loop 1 Loop 2 Loop 3 Loop 4
161 361 561 761 SELMD Two-input changeover mode RW 
C3.11162 362 562 762 SELH Two-input changeover upper limit RW 
163 363 563 763 SELL Two-input changeover lower limit RW 
164 364 564 764 SPH Upper SP limit RW 
C4.3
165 365 565 765 SPL Lower SP limit RW 
166 366 566 766 SPR.UP SP up gradient RW 
C4.4
167 367 567 767 SPR.DN SP down gradient RW 
168 368 568 768 SPR.TM SP gradient time unit RW 
169 369 569 769 SP.TR SP tracking mode RW  C4.6
170 370 570 770 Not used
171 371 571 771 BS Fixed bias RW  C3.8
172 372 572 772 FL Input filter RW  C3.10
173 373 573 773 X1 Broken-line input 1 RW 
C3.7
174 374 574 774 Y1 Broken-line bias 1 RW 
175 375 575 775 X2 Broken-line input 2 RW 
176 376 576 776 Y2 Broken-line bias 2 RW 
177 377 577 777 X3 Broken-line input 3 RW 
178 378 578 778 Y3 Broken-line bias 3 RW 
179 379 579 779 SR Square root extraction RW 
C3.9
180 380 580 780 LC Low-cut RW 
181 381 581 781 SELF Dynamic auto-tuning enable RW  C5.1
182 382 582 782 SC “Super” enable code RW  C6.7
183 383 583 783 ARW ARW setting RW  C6.8
184 384 584 784 CMD Control mode RW  C6.6
185 385 585 785 ZONE Zone PID selection RW  C6.9
186 386 586 786 1RP Reference point 1 RW  C6.9.2
187 387 587 787 2RP Reference point 2 RW 
C6.9.2
188 388 588 788 RHY Zone switching hysteresis RW 
189 389 589 789 RDV Reference deviation RW 
190 390 590 790 Not used
191 391 591 791 CT Cycle time RW  C2.4.2
192 392 592 792 CTc Cooling cycle time RW  —
193 393 593 793 MVR Rate-of-change limit RW  C2.4.2
194 394 594 794
Not used
195 395 595 795
196 396 596 796
197 397 597 797
198 398 598 798
199 399 599 799
200 400 600 800
