YOKOGAWA F3CU04-0S User Manual

E1-6
IM 34M06H62-02E 2nd Edition : June 2008-00
Table E1.9 Operation Parameters (2/3)
Data Position Number
Symbol Description Attribute Stored See Also
Loop 1 Loop 2 Loop 3 Loop 4
201 401 601 801 1.SP Set point RW Irregular
B2.4
C4.1
202 402 602 802 1.A1 Alarm 1 preset value RW 
C8.1
203 403 603 803 1.A2 Alarm 2 preset value RW 
204 404 604 804 1.A3 Alarm 3 preset value RW 
205 405 605 805 1.A4 Alarm 4 preset value RW 
206 406 606 806 1.PB Proportional band RW  C6.2
207 407 607 807 1.TI Integral time RW  C6.3
208 408 608 808 1.TD Derivative time RW  C6.4
209 409 609 809 1.OH Upper output limit RW 
C2.4.2
210 410 610 810 1.OL Lower output limit RW 
211 411 611 811 1.MR Manual reset value RW  C6.3
212 412 612 812 1.HYS ON/OFF control hysteresis RW  C2.4.1
213 413 613 813 1.DR Forward/reverse switch RW  C6.1
214 414 614 814 1.GAIN.C Cooling gain RW  C2.4.3
215 415 615 815 1.HYS.C Cooling ON/OFF control hysteresis RW  C2.4.4
216 416 616 816 1.DB Dead band RW 
C2.4.3
C2.4.4
217 417 617 817 1.POUT Preset output RW 
C7.1
218 418 618 818 1.POUT.C Cooling preset output RW 
219 419 619 819
Not used
220 420 620 820
221 421 621 821 2.SP Set point RW Irregular
B2.4
C4.1
222 422 622 822 2.A1 Alarm 1 preset value RW 
C8.1
223 423 623 823 2.A2 Alarm 2 preset value RW 
224 424 624 824 2.A3 Alarm 3 preset value RW 
225 425 625 825 2.A4 Alarm 4 preset value RW 
226 426 626 826 2.PB Proportional band RW  C6.2
227 427 627 827 2.TI Integral time RW  C6.3
228 428 628 828 2.TD Derivative time RW  C6.4
229 429 629 829 2.OH Upper output limit RW 
C2.4.2
230 430 630 830 2.OL Lower output limit RW 
231 431 631 831 2.MR Manual reset value RW  C6.3
232 432 632 832 2.HYS ON/OFF control hysteresis RW  C2.4.1
233 433 633 833 2.DR Forward/reverse switch RW  C6.1
234 434 634 834 2.GAIN.C Cooling gain RW  C2.4.3
235 435 635 835 2.HYS.C Cooling ON/OFF control hysteresis RW  C2.4.4
236 436 636 836 2.DB Dead band RW 
C2.4.3
C2.4.4
237 437 637 837 2.POUT Preset output RW 
C7.1
238 438 638 838 2.POUT.C Cooling preset output RW 
239 439 639 839
Not used
240 440 640 840
Irregular: You need to execute a specific procedure every time to update stored set point values.
